Q6016LH1LED Series

Altnstr 600V 16A 80-80-80 mA TO220 Iso

Manufacturer: Littelfuse/Commercial Vehicle Products

Catalog

Altnstr 600V 16A 80-80-80 mA TO220 Iso

Part	Operating Temperature [Min]	Operating Temperature [Max]	Current - On State (It (RMS)) (Max)	Current - Non Rep. Surge 50, 60Hz (Itsm)	Voltage - Off State	Package / Case	Triac Type	Configuration	Voltage - Gate Trigger (Vgt) (Max) [Max]	Current - Gate Trigger (Igt) (Max) [Max]	Current - Hold (Ih) (Max) [Max]	Mounting Type	Supplier Device Package	Current - Gate Trigger (Igt) (Max) [Max] [custom]	Current - Gate Trigger (Igt) (Max) [Max] [x]
Littelfuse/Commercial Vehicle Products Q6016NH3RP	-40 °C	125 ¯C	16 A	167 A 200 A	600 V	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	Alternistor - Snubberless	Single	1.3 V	20 mA	35 mA	Surface Mount	TO-263 (D2PAK)
Littelfuse/Commercial Vehicle Products Q6016RH4TP	-40 °C	125 ¯C	16 A	167 A 200 A	600 V	TO-220-3	Alternistor - Snubberless	Single	1.3 V	35 mA	50 mA	Through Hole	TO-220AB
Littelfuse/Commercial Vehicle Products Q6016NH6RP	-40 °C	125 ¯C	16 A	167 A 200 A	600 V	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	Alternistor - Snubberless	Single	1.3 V		70 mA	Surface Mount	TO-263 (D2PAK)	80 mA
Littelfuse/Commercial Vehicle Products Q6016LH2	-40 °C	125 ¯C	16 A	167 A 200 A	600 V	TO-220-3 Isolated Tab	Alternistor - Snubberless	Single	1.3 V	10 mA	15 mA	Through Hole	TO-220 Isolated Tab
Littelfuse/Commercial Vehicle Products Q6016LH2TP	-40 °C	125 ¯C	16 A	167 A 200 A	600 V	TO-220-3 Isolated Tab	Alternistor - Snubberless	Single	1.3 V	10 mA	15 mA	Through Hole	TO-220 Isolated Tab
Littelfuse/Commercial Vehicle Products Q6016LH1LEDTP	-40 °C	125 ¯C		167 A 200 A	600 V	TO-220-3 Full Pack Isolated Tab	Standard	Single	2 V		5 mA	Through Hole	ITO-220AB		100 mA
Littelfuse/Commercial Vehicle Products Q6016RH657	-40 °C	125 ¯C	16 A	167 A 200 A	600 V	TO-220-3 Formed Leads	Alternistor - Snubberless	Single	1.3 V		70 mA	Through Hole	TO-220AB	80 mA
Littelfuse/Commercial Vehicle Products Q6016NH3TP	-40 °C	125 ¯C	16 A	167 A 200 A	600 V	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	Alternistor - Snubberless	Single	1.3 V	20 mA	35 mA	Surface Mount	TO-263 (D2PAK)
Littelfuse/Commercial Vehicle Products Q6016NH2RP	-40 °C	125 ¯C	16 A	167 A 200 A	600 V	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	Alternistor - Snubberless	Single	1.3 V	10 mA	15 mA	Surface Mount	TO-263 (D2PAK)
Littelfuse/Commercial Vehicle Products Q6016LH6TP	-40 °C	125 ¯C	16 A	167 A 200 A	600 V	TO-220-3 Isolated Tab	Alternistor - Snubberless	Single	1.3 V		70 mA	Through Hole	TO-220 Isolated Tab	80 mA

Catalog

Altnstr 600V 16A 80-80-80 mA TO220 Iso

Key Features

• RoHS Compliant

• Glass - passivated junctions

• Voltage capability up to 1000 V

• Surge capability up to 200 A

• Electrically isolated package "L - Package" and UL recognized for 2500Vrms

• Solid-state switching eliminates arcing or contact bounce that create voltage transients

• No contacts to wear out from reaction of switching events

• Restricted (or limited) RFI generation, depending on activation point sine wave

• Requires only a small gate activation pulse in each half-cycle

Description

Q6016LH1LED series is designed to meet low load current characteristics typical in LED lighting applications. By keeping holding current at 5mA maximum, this Triac series is characterized and specified to perform best with LED loads. The Q6016LH1LED series is best suited for LED dimming controls to obtain the lowest levels of light output with a minimum probability of flickering. Q6016LH1LED series is offered in the industry standard TO-220AB package with an isolated mounting tab that makes it best suited for adding an external heat sink.
