55.32.8 Series

Catalog

RELAY GEN PURPOSE DPDT 10A 24V

Part	Coil Resistance	Coil Type	Mounting Type	Must Release Voltage	Coil Current	Must Operate Voltage	Operate Time	Contact Rating (Current)	Termination Style	Relay Type	Load - Max Switching [Max]	Coil Voltage	Switching Voltage [Max]	Approval Agency	Contact Material	Release Time	Operating Temperature [Max]	Operating Temperature [Min]	Contact Form	Features
Finder Relays, Inc. 55.32.8.024.0000	190 Ohms	Non Latching	Socketable	4.8 VAC	53 mA	19.2 VAC	10 ms	10 A	Plug In	General Purpose	4000 VA	24 VAC	400 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Silver Nickel (AgNi)	5 ms	85 °C	-40 C	DPDT (2 Form C)
Finder Relays, Inc. 55.32.8.024.5030	190 Ohms	Non Latching	Socketable	4.8 VAC	53 mA	19.2 VAC	10 ms	10 A	Plug In	General Purpose	4000 VA	24 VAC	400 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Gold (Au) Silver Nickel (AgNi)	5 ms	85 °C	-40 C	DPDT (2 Form C)	Lighted Indicator
Finder Relays, Inc. 55.32.8.230.0054	17 kOhms	Non Latching	Socketable	46 VAC	6 mA	184 VAC	10 ms	10 A	Plug In	General Purpose	4000 VA	230 VAC	400 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Silver Nickel (AgNi)	5 ms	85 °C	-40 C	DPDT (2 Form C)
Finder Relays, Inc. 55.32.8.230.5000	17 kOhms	Non Latching	Socketable	46 VAC	6 mA	184 VAC	10 ms	10 A	Plug In	General Purpose	4000 VA	230 VAC	400 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Gold (Au) Silver Nickel (AgNi)	5 ms	85 °C	-40 C	DPDT (2 Form C)
Finder Relays, Inc. 55.32.8.240.0000	19.1 kOhms	Non Latching	Socketable	48 VAC	5.3 mA	192 VAC	10 ms	10 A	Plug In	General Purpose	4000 VA	240 VAC/DC	400 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Silver Nickel (AgNi)	5 ms	85 °C	-40 C	DPDT (2 Form C)
Finder Relays, Inc. 55.32.8.024.0054	190 Ohms	Non Latching	Socketable	4.8 VAC	53 mA	19.2 VAC	10 ms	10 A	Plug In	General Purpose	4000 VA	24 VAC	400 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Silver Nickel (AgNi)	5 ms	85 °C	-40 C	DPDT (2 Form C)
Finder Relays, Inc. 55.32.8.110.0050	3.94 kOhms	Non Latching	Socketable	22 VAC		88 VAC/DC	10 ms	10 A	Plug In	General Purpose	4000 VA	110 VAC/DC	400 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Silver Nickel (AgNi)	5 ms	85 °C	-40 C	DPDT (2 Form C)	Lighted Indicator Test Button
Finder Relays, Inc. 55.32.8.230.0000	17 kOhms	Non Latching	Socketable	46 VAC	6 mA	184 VAC	10 ms	10 A	Plug In	General Purpose	4000 VA	230 VAC	400 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Silver Nickel (AgNi)	5 ms	85 °C	-40 C	DPDT (2 Form C)
Finder Relays, Inc. 55.32.8.230.0040	17 kOhms	Non Latching	Socketable	46 VAC	6 mA	184 VAC	10 ms	10 A	Plug In	General Purpose	4000 VA	230 VAC	400 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Silver Nickel (AgNi)	5 ms	85 °C	-40 C	DPDT (2 Form C)	Mechanical Indicator Test Button
Finder Relays, Inc. 55.32.8.024.0030	190 Ohms	Non Latching	Socketable	4.8 VAC	53 mA	19.2 VAC	10 ms	10 A	Plug In	General Purpose	4000 VA	24 VAC	400 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Silver Nickel (AgNi)	5 ms	85 °C	-40 C	DPDT (2 Form C)	Lighted Indicator
