395-042 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Termination Rows | Material - Insulation | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Termination | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions | Contact Finish | Card Type | Number of Positions/Bay/Row | Contact Material | Gender | Pitch | Pitch | Number of Rows | Contact Type | Color | Flange Feature | Features | Termination Rows [custom] | Number of Positions/Bay/Row [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 42 | Gold | Non Specified - Single Edge | 42 | Copper Alloy | Female | 0.1 " | 2.54 mm | 1 | Cantilever | Black | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | 0.25 Ám | 10 Áin | 42 | Gold | Non Specified - Single Edge | 42 | Copper Alloy | Female | 0.1 " | 2.54 mm | 1 | Cantilever | Black | |||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 42 | Gold | Non Specified - Single Edge | 42 | Copper Alloy | Female | 0.1 " | 2.54 mm | 1 | Cantilever | Black | Flush Mount Top Opening Unthreaded | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | 0.25 Ám | 10 Áin | 42 | Gold | Non Specified - Single Edge | 42 | Copper Alloy | Female | 0.1 " | 2.54 mm | 1 | Cantilever | Black | 4-40 Threaded Insert Top Mount Opening | Card Guides | |||||
 EDAC Inc. | Polyester Thermoplastic | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 42 | Gold | Non Specified - Dual Edge | Copper Alloy | Female | 0.1 " | 2.54 mm | Cantilever | Black | 2 | 21 | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 42 | Gold | Non Specified - Dual Edge | Copper Alloy | Female | 0.1 " | 2.54 mm | Cantilever | Black | 2 | 21 | 2 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | 42 | Gold | Non Specified - Single Edge | 42 | Copper Alloy | Female | 0.1 " | 2.54 mm | 1 | Cantilever | Black | Side Mount Opening Unthreaded | ||||
 EDAC Inc. | Polyester Thermoplastic | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | 42 | Gold | Non Specified - Dual Edge | Copper Alloy | Female | 0.1 " | 2.54 mm | Cantilever | Black | 2 | 21 | 2 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | 42 | Gold | Non Specified - Single Edge | 42 | Copper Alloy | Female | 0.1 " | 2.54 mm | 1 | Cantilever | Black | Flush Mount Top Opening Unthreaded | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | 0.25 Ám | 10 Áin | 42 | Gold | Non Specified - Single Edge | 42 | Copper Alloy | Female | 0.1 " | 2.54 mm | 1 | Cantilever | Black | 4-40 Flush Mount Threaded Insert Top Opening |
