316-032 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 64POS 0.156
| Part | Material - Insulation | Termination Rows | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Card Type | Number of Positions | Pitch | Pitch | Number of Positions/Bay/Row | Flange Feature | Card Thickness [Max] | Card Thickness [Min] | Gender | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Termination | Contact Material | Contact Finish | Read Out | Color | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 64 | 3.96 mm | 0.156 in | 32 | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Panel Mount Through Hole | Solder | Copper Alloy | Gold | Dual | Green | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 64 | 3.96 mm | 0.156 in | 32 | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Panel Mount Through Hole | Solder | Copper Alloy | Gold | Dual | Green | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 64 | 3.96 mm | 0.156 in | 32 | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Panel Mount Through Hole | Solder | Copper Alloy | Gold | Dual | Green | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 64 | 3.96 mm | 0.156 in | 32 | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Panel Mount | Solder Eyelet(s) | Copper Alloy | Tin | Dual | Green | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 64 | 3.96 mm | 0.156 in | 32 | Floating Bobbin Flush Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Panel Mount | Solder Eyelet(s) | Copper Alloy | Tin | Dual | Green | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 64 | 3.96 mm | 0.156 in | 32 | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Panel Mount | Solder Eyelet(s) | Copper Alloy | Tin | Dual | Green | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 64 | 3.96 mm | 0.156 in | 32 | Floating Bobbin Flush Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Panel Mount Through Hole | Solder | Copper Alloy | Gold | Dual | Green | 0.116 " | 2.95 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 64 | 3.96 mm | 0.156 in | 32 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Through Hole | Solder | Copper Alloy | Tin | Dual | Green | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 64 | 3.96 mm | 0.156 in | 32 | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Panel Mount Through Hole | Solder | Copper Alloy | Gold | Dual | Green | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 64 | 3.96 mm | 0.156 in | 32 | Flush Mount Side Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Panel Mount Through Hole | Solder | Copper Alloy | Gold | Dual | Green | 0.128 " | 3.25 mm |
