846-090 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 90POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Read Out | Color | Number of Positions | Card Type | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Mounting Type | Gender | Pitch | Pitch | Contact Type | Termination | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Green | 90 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 2 | Through Hole | Female | 3.18 mm | 0.125 in | Cantilever | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 45 | 125 °C | -40 C | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Green | 90 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 2 | Through Hole | Female | 3.18 mm | 0.125 in | Cantilever | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 45 | 125 °C | -40 C | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Green | 90 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 2 | Board Edge Straddle Mount | Female | 3.18 mm | 0.125 in | Cantilever | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 45 | 125 °C | -40 C | Card Extender |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Green | 90 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Through Hole | Female | 3.18 mm | 0.125 in | Cantilever | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 45 | 125 °C | -40 C | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Green | 90 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Through Hole | Female | 3.18 mm | 0.125 in | Cantilever | Solder Eyelet(s) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 45 | 125 °C | -40 C | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Green | 90 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 0.156 " | 3.96 mm | 2 | Board Edge Straddle Mount | Female | 3.18 mm | 0.125 in | Cantilever | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 45 | 125 °C | -40 C | Card Extender | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Green | 90 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Through Hole | Female | 3.18 mm | 0.125 in | Cantilever | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 45 | 125 °C | -40 C | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Green | 90 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 0.156 " | 3.96 mm | 2 | Through Hole | Female | 3.18 mm | 0.125 in | Cantilever | Solder Eyelet(s) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 45 | 125 °C | -40 C | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Green | 90 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | 2 | Board Edge Straddle Mount | Female | 3.18 mm | 0.125 in | Cantilever | Solder Eyelet(s) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 45 | 125 °C | -40 C | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Green | 90 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Board Edge Straddle Mount | Female | 3.18 mm | 0.125 in | Cantilever | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 45 | 125 °C | -40 C | Card Extender |
