ND35B00 Series
Manufacturer: Delta Electronics
Beta
⌘K
FAN BLOWER 30X4.5MM 5VDC WIRE
| Part | Current Rating (Amps) | Voltage Range [Max] | Voltage Range [Min] | Material - Blade | Lifetime @ Temp. | Material - Frame | RPM | Approval Agency | Weight [custom] | Weight [custom] | Air Flow | Air Flow | Termination | Bearing Type | Fan Type | Size / Dimension [x] | Size / Dimension [z] | Static Pressure | Static Pressure | Voltage - Rated | Operating Temperature [Min] | Operating Temperature [Max] | Power (Watts) | Noise | Width [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics | 100 mA | 5.5 V | 4.5 V | Plastic | 30000 Hrs | Plastic | 10500 RPM | cURus TUV | 4.99 g | 0.011 lb | 1.1 CFM | 0.031 m³/min | 4 Wire Leads | Sleeve | Blower | 30 mm | 30 mm | 102 Pa | 0.409 in H2O | 5 V | -10 °C | 60 °C | 0.5 W | 49.5 dB | 4.5 mm |
