1241.1032 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
SWITCH TACTILE SPST-NO 0.05A 24V
| Part | Actuator Material | Mechanical Life | Switch Travel | Features | Outline [x] | Outline [y] | Operating Force | Actuator Type | Contact Rating @ Voltage | Circuit | Termination Style | Mounting Type | Actuator Orientation | Switch Function | Ingress Protection | Operating Temperature [Max] | Operating Temperature [Min] | Actuator Height off PCB, Vertical [z] | Illumination | Actuator Height off PCB, Vertical |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | Polycarbonate (PC) | 1000000 Cycles | 0.45 mm | Tactile Feedback | 12.65 mm | 12.65 mm | 0.25 kgf | Standard | 0.05 A 24 VDC | SPST-NO | PC Pin | Through Hole | Top Actuated | Off-Mom | IP40 | 85 °C | -25 °C | 12.25 mm | Non-Illuminated | |
 SCHURTER Inc. | Polycarbonate (PC) | 1000000 Cycles | 0.45 mm | Tactile Feedback | 12.65 mm | 12.65 mm | 0.25 kgf | Standard | 0.05 A 24 VDC | SPST-NO | PC Pin | Through Hole | Top Actuated | Off-Mom | IP40 | 85 °C | -25 °C | 10.75 mm | Non-Illuminated | |
 SCHURTER Inc. | Polycarbonate (PC) | 1000000 Cycles | 0.45 mm | Tactile Feedback | 12.65 mm | 12.65 mm | 0.25 kgf | Standard | 0.05 A 24 VDC | SPST-NO | PC Pin | Through Hole | Top Actuated | Off-Mom | IP40 | 85 °C | -25 °C | 9.25 mm | Non-Illuminated | |
 SCHURTER Inc. | Polycarbonate (PC) | 1000000 Cycles | 0.45 mm | Tactile Feedback | 12.65 mm | 12.65 mm | 0.25 kgf | Standard | 0.05 A 24 VDC | SPST-NO | PC Pin | Through Hole | Top Actuated | Off-Mom | IP40 | 85 °C | -25 °C | 10 mm | Non-Illuminated | |
 SCHURTER Inc. | Polycarbonate (PC) | 1000000 Cycles | 0.45 mm | Tactile Feedback | 12.65 mm | 12.65 mm | 0.25 kgf | Standard | 0.05 A 24 VDC | SPST-NO | PC Pin | Through Hole | Top Actuated | Off-Mom | IP40 | 85 °C | -25 °C | Non-Illuminated | 13 mm |
