ESK225M Series

Manufacturer: KEMET

Catalog

CAP ALUM 2.2UF 20% 100V RADIAL

Part	Tolerance	Polarization	Size / Dimension [diameter]	Size / Dimension [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Lifetime @ Temp.	Ripple Current @ High Frequency	Capacitance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Lead Spacing	Lead Spacing	Package / Case	Applications	Ripple Current @ Low Frequency	Voltage - Rated
KEMET ESK225M100AC3FA	20 %	Polar	0.197 in	5 mm	85 °C	-40 C	Through Hole	2000 Hrs	45 mA	2.2 µF	0.492 in	12.5 mm	2 mm	0.079 in	Can Radial	General Purpose	30 mA	100 V
KEMET ESK225M050AC3KA	20 %	Polar	0.197 in	5 mm	85 °C	-40 C	Through Hole	2000 Hrs	34.5 mA	2.2 µF	0.492 in	12.5 mm	2 mm	0.079 in	Can Radial	General Purpose	23 mA	50 VDC
KEMET ESK225M050AC3AA	20 %	Polar	0.197 in	5 mm	85 °C	-40 C	Through Hole	2000 Hrs	34.5 mA	2.2 µF	0.492 in	12.5 mm	2 mm	0.079 in	Can Radial	General Purpose	23 mA	50 VDC
