337-040 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 40POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Termination | Contact Finish | Card Type | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Read Out | Contact Material | Number of Rows [custom] | Number of Positions/Bay/Row | Gender | Color | Mounting Type | Pitch | Pitch | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Termination Rows | Number of Rows | Flange Feature | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 40 | Solder | Gold | Non Specified - Dual Edge | Cantilever | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 2 | 20 Bay/Row | Female | Green | Through Hole | 3.96 mm | 0.156 in | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 40 | Solder Eyelet(s) | Gold | Non Specified - Single Edge | Cantilever | 0.25 Ám | 10 Áin | Single | Copper Alloy | Female | Green | Through Hole | 3.96 mm | 0.156 in | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | Flush Mount Side Opening Unthreaded | 40 | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 40 | Wire Wrap | Gold | Non Specified - Single Edge | Cantilever | 0.25 Ám | 10 Áin | Single | Copper Alloy | Female | Green | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | Flush Mount M3 Threaded Insert Top Opening | 40 | ||||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 40 | Wire Wrap | Gold | Non Specified - Single Edge | Cantilever | 0.25 Ám | 10 Áin | Single | Copper Alloy | Female | Green | Through Hole | 3.96 mm | 0.156 in | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | Floating Bobbin Top Mount Opening | 40 | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 40 | Solder | Gold | Non Specified - Dual Edge | Cantilever | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 2 | 20 Bay/Row | Female | Green | Through Hole | 3.96 mm | 0.156 in | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 40 | Solder Eyelet(s) | Gold | Non Specified - Dual Edge | Cantilever | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 2 | 20 Bay/Row | Female | Green | Through Hole | 3.96 mm | 0.156 in | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 40 | Wire Wrap | Gold | Non Specified - Single Edge | Cantilever | 0.25 Ám | 10 Áin | Single | Copper Alloy | Female | Green | Through Hole | 3.96 mm | 0.156 in | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | 40 | |||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 40 | Wire Wrap | Gold | Non Specified - Single Edge | Cantilever | 0.25 Ám | 10 Áin | Single | Copper Alloy | Female | Green | Right Angle Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | 4-40 Threaded Insert Top Mount Opening | 40 | Card Guides | |||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 40 | Wire Wrap | Gold | Non Specified - Single Edge | Cantilever | 0.25 Ám | 10 Áin | Single | Copper Alloy | Female | Green | Through Hole | 3.96 mm | 0.156 in | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | Floating Bobbin Top Mount Opening | 40 | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 40 | Solder | Gold | Non Specified - Dual Edge | Cantilever | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 2 | 20 Bay/Row | Female | Green | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening |
