896-022 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 22POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Termination | Mounting Type | Features | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row | Pitch | Pitch | Contact Finish | Number of Rows [custom] | Contact Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Read Out | Gender | Card Type | Color | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Board Edge Straddle Mount | Card Extender | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 11 | 3.18 mm | 0.125 in | Gold | 2 | Cantilever | 22 | 0.25 Ám | 10 Áin | Dual | Female | Non Specified - Dual Edge | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder Eyelet(s) | Board Edge Straddle Mount | Card Extender | M3 Threaded Insert Top Mount Opening | 11 | 3.18 mm | 0.125 in | Gold | 2 | Cantilever | 22 | 0.25 Ám | 10 Áin | Dual | Female | Non Specified - Dual Edge | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Through Hole | 0.128 " | 3.25 mm | 11 | 3.18 mm | 0.125 in | Gold | 2 | Cantilever | 22 | 0.25 Ám | 10 Áin | Dual | Female | Non Specified - Dual Edge | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Through Hole | 4-40 Threaded Insert Top Mount Opening | 11 | 3.18 mm | 0.125 in | Gold | 2 | Cantilever | 22 | 0.25 Ám | 10 Áin | Dual | Female | Non Specified - Dual Edge | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Wire Wrap | Through Hole | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 22 | 3.18 mm | 0.125 in | Gold | Cantilever | 22 | 0.25 Ám | 10 Áin | Single | Female | Non Specified - Single Edge | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 1 | 1 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Through Hole | Flush Mount M3 Threaded Insert Top Opening | 11 | 3.18 mm | 0.125 in | Gold | 2 | Cantilever | 22 | 0.25 Ám | 10 Áin | Dual | Female | Non Specified - Dual Edge | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Right Angle Through Hole | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 11 | 3.18 mm | 0.125 in | Gold | 2 | Cantilever | 22 | 0.25 Ám | 10 Áin | Dual | Female | Non Specified - Dual Edge | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Through Hole | 4-40 Threaded Insert Top Mount Opening | 11 | 3.18 mm | 0.125 in | Gold | 2 | Cantilever | 22 | 0.25 Ám | 10 Áin | Dual | Female | Non Specified - Dual Edge | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Right Angle Through Hole | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 22 | 3.18 mm | 0.125 in | Gold | Cantilever | 22 | 0.25 Ám | 10 Áin | Single | Female | Non Specified - Single Edge | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 1 | 1 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Board Edge Straddle Mount | Card Extender | 0.156 " | 3.96 mm | 11 | 3.18 mm | 0.125 in | Gold | 2 | Cantilever | 22 | 0.25 Ám | 10 Áin | Dual | Female | Non Specified - Dual Edge | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C |
