207478 Series
KK Plus 396 Header, 3.96mm Pitch, Vertical, Unshrouded, Tin (Sn) Plating, 4 Circuits, without Peg
Manufacturer: Molex
Catalog
KK Plus 396 Header, 3.96mm Pitch, Vertical, Unshrouded, Tin (Sn) Plating, 4 Circuits, without Peg
Beta
⌘K
KK Plus 396 Header, 3.96mm Pitch, Vertical, Unshrouded, Tin (Sn) Plating, 4 Circuits, without Peg
KK Plus 396 Header, 3.96mm Pitch, Vertical, Unshrouded, Tin (Sn) Plating, 4 Circuits, without Peg
KK Plus 396 Header, 3.96mm Pitch, Vertical, Unshrouded, Tin (Sn) Plating, 4 Circuits, without Peg
| Part | Overall Contact Length | Overall Contact Length | Number of Rows | Connector Type | Applications | Contact Shape | Current Rating (Amps) | Mounting Type | Style | Number of Positions Loaded | Fastening Type | Contact Type | Shrouding | Operating Temperature [Min] | Operating Temperature [Max] | Pitch - Mating | Pitch - Mating | Contact Finish - Post | Voltage Rating | Contact Length - Post | Contact Length - Post | Insulation Color | Material Flammability Rating | Termination | Contact Material | Features | Insulation Height [z] | Insulation Height [z] | Insulation Material | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 17.6 mm | 0.693 in | 1 | Header | Automotive General Purpose Industrial Medical Telecommunications | Square | Varies by Wire Gauge | Through Hole | Board to Cable/Wire | All | Latch Holder | Male Pin | Shrouded - 1 Wall | -40 °C | 105 ░C | 0.156 in | 3.96 mm | Tin | 350 V | 3.5 mm | 0.138 in | Black | UL94 V-0 | Solder | Brass Alloy | Board Guide Glow Wire Compliant | 12.1 mm | 0.476 in | Liquid Crystal Polymer (LCP) | |
 Molex | 17.6 mm | 0.693 in | 1 | Header | Automotive General Purpose Industrial Medical Telecommunications | Square | Varies by Wire Gauge | Through Hole | Board to Cable/Wire | All | Latch Holder | Male Pin | Shrouded - 1 Wall | -40 °C | 105 ░C | 0.156 in | 3.96 mm | Tin | 350 V | 3.5 mm | 0.138 in | Black | UL94 V-0 | Solder | Brass Alloy | Board Guide Glow Wire Compliant | 12.1 mm | 0.476 in | Liquid Crystal Polymer (LCP) | 2 |
 Molex | 17.6 mm | 0.693 in | 1 | Header | Automotive General Purpose Industrial Medical Telecommunications | Square | Varies by Wire Gauge | Through Hole | Board to Cable/Wire | All | Latch Holder | Male Pin | Shrouded - 1 Wall | -40 °C | 105 ░C | 0.156 in | 3.96 mm | Tin | 350 V | 3.5 mm | 0.138 in | Black | UL94 V-0 | Solder | Brass Alloy | Board Guide Glow Wire Compliant | 12.1 mm | 0.476 in | Liquid Crystal Polymer (LCP) | 4 |
 Molex | 17.6 mm | 0.693 in | 1 | Header | Automotive General Purpose Industrial Medical Telecommunications | Square | Varies by Wire Gauge | Through Hole | Board to Cable/Wire | All | Latch Holder | Male Pin | Shrouded - 1 Wall | -40 °C | 105 ░C | 0.156 in | 3.96 mm | Tin | 350 V | 3.5 mm | 0.138 in | Black | UL94 V-0 | Solder | Brass Alloy | Glow Wire Compliant | 12.1 mm | 0.476 in | Liquid Crystal Polymer (LCP) | 4 |
 Molex | 17.6 mm | 0.693 in | 1 | Header | Automotive General Purpose Industrial Medical Telecommunications | Square | Varies by Wire Gauge | Through Hole | Board to Cable/Wire | All | Latch Holder | Male Pin | Shrouded - 1 Wall | -40 °C | 105 ░C | 0.156 in | 3.96 mm | Tin | 350 V | 3.5 mm | 0.138 in | Black | UL94 V-0 | Solder | Brass Alloy | Glow Wire Compliant | 12.1 mm | 0.476 in | Liquid Crystal Polymer (LCP) | 6 |
 Molex | 17.6 mm | 0.693 in | 1 | Header | Automotive General Purpose Industrial Medical Telecommunications | Square | Varies by Wire Gauge | Through Hole | Board to Cable/Wire | All | Latch Holder | Male Pin | Shrouded - 1 Wall | -40 °C | 105 ░C | 0.156 in | 3.96 mm | Tin | 350 V | 3.5 mm | 0.138 in | Black | UL94 V-0 | Solder | Brass Alloy | Glow Wire Compliant | 12.1 mm | 0.476 in | Liquid Crystal Polymer (LCP) | 2 |
 Molex | 17.6 mm | 0.693 in | 1 | Header | Automotive General Purpose Industrial Medical Telecommunications | Square | Varies by Wire Gauge | Through Hole | Board to Cable/Wire | All | Latch Holder | Male Pin | Shrouded - 1 Wall | -40 °C | 105 ░C | 0.156 in | 3.96 mm | Tin | 350 V | 3.5 mm | 0.138 in | Black | UL94 V-0 | Solder | Brass Alloy | Board Guide Glow Wire Compliant | 12.1 mm | 0.476 in | Liquid Crystal Polymer (LCP) | 6 |
