FA5S050H Series

Catalog

CONN FPC BOTTOM 50POS 0.5MM R/A

Part	Mating Cycles	Housing Color	Current Rating (Amps)	Actuator Color	FFC, FCB Thickness	Mounting Type	Termination	Connector/Contact Type	Cable End Type	Contact Finish	Height Above Board [z]	Height Above Board [z]	Actuator Material	Contact Material	Operating Temperature [Max]	Operating Temperature [Min]	Number of Positions	Locking Feature	Voltage Rating	Material Flammability Rating	Flat Flex Type	Pitch	Pitch	Features	Housing Material
JAE Electronics FA5S050HP1	20	Black	0.8 A	White	0.3 mm	Right Angle Surface Mount	Solder	Contacts Bottom	Tapered	Gold	1.45 mm	0.057 in	Glass Filled Nylon Polyamide (PA)	Copper Alloy	85 °C	-40 C	50	Flip Lock	50 V	UL94 V-0	FPC	0.02 "	0.5 mm	Solder Retention Zero Insertion Force (ZIF)	Glass Filled Liquid Crystal Polymer (LCP)
JAE Electronics FA5S050HP1R3000	20	Black	0.8 A	White	0.3 mm	Right Angle Surface Mount	Solder	Contacts Bottom	Tapered	Gold	1.45 mm	0.057 in	Glass Filled Nylon Polyamide (PA)	Copper Alloy	85 °C	-40 C	50	Flip Lock	50 V	UL94 V-0	FPC	0.02 "	0.5 mm	Solder Retention Zero Insertion Force (ZIF)	Glass Filled Liquid Crystal Polymer (LCP)
