895-130 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 130POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Mounting Type | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Number of Rows [custom] | Color | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Gender | Number of Positions/Bay/Row | Features | Flange Feature | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Card Type | Contact Material | Contact Type | Termination | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Board Edge Straddle Mount | 130 | 125 °C | -40 C | Dual | 2 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 65 | Card Extender | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Cantilever | Solder | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Board Edge Straddle Mount | 130 | 125 °C | -40 C | Dual | 2 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 65 | Card Extender | Flush Mount Side Opening Unthreaded | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Cantilever | Solder | 0.128 " | 3.25 mm |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Board Edge Straddle Mount | 130 | 125 °C | -40 C | Dual | 2 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 65 | Card Extender | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Cantilever | Solder | 0.156 " | 3.96 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 130 | 125 °C | -40 C | Dual | 2 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 65 | 4-40 Threaded Insert Top Mount Opening | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Cantilever | Solder | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 130 | 125 °C | -40 C | Dual | 2 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 65 | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Cantilever | Solder | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Board Edge Straddle Mount | 130 | 125 °C | -40 C | Dual | 2 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 65 | Card Extender | Floating Bobbin Top Mount Opening | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Cantilever | Solder | 0.116 " | 2.95 mm |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 130 | 125 °C | -40 C | Dual | 2 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 65 | Floating Bobbin Flush Mount | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Cantilever | Wire Wrap | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 130 | 125 °C | -40 C | Dual | 2 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 65 | Floating Bobbin Top Mount Opening | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Cantilever | Solder | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 130 | 125 °C | -40 C | Dual | 2 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 65 | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Cantilever | Wire Wrap | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 130 | 125 °C | -40 C | Dual | 2 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 65 | 4-40 Threaded Insert Top Mount Opening | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Cantilever | Solder |
