Fixed Terminal Blocks SPT-SMD 1,5/10-H-3,5 R72
Fixed Terminal Blocks SPT-SMD 1,5/10-H-3,5 R72
| Part | Housing Material | Contact Material - Plating | Current | Color | Positions Per Level | Mating Orientation | Wire Termination | Number of Levels | Wire Gauge [Max] | Wire Gauge [Min] | Voltage | Pitch | Pitch | Mounting Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | Liquid Crystal Polymer (LCP) | Tin Plated | 10 A | Black | 12 | Vertical with Board | Leg Spring Push-In Spring | 1 | 24 AWG | 16 AWG | 300 VDC | 3.5 mm | 0.138 " | Surface Mount | |
 Phoenix Contact | 10 A | Black | 6 | Horizontal with Board | Leg Spring Push-In Spring | 1 | 24 AWG | 16 AWG | 300 VDC | 5 mm | 0.197 in | Surface Mount | Board Guide | ||
 Phoenix Contact | 10 A | Black | 5 | Horizontal with Board | Leg Spring Push-In Spring | 1 | 24 AWG | 16 AWG | 300 VDC | 5 mm | 0.197 in | Surface Mount | Board Guide | ||
 Phoenix Contact | Liquid Crystal Polymer (LCP) | Tin Plated | 10 A | Black | 6 | Horizontal with Board | Leg Spring Push-In Spring | 1 | 24 AWG | 16 AWG | 300 VDC | 5.08 mm | 0.2 in | Surface Mount | Board Guide |
Phoenix Contact | Liquid Crystal Polymer (LCP) | Tin Plated | 10 A | Black | 12 | Vertical with Board | Leg Spring Push-In Spring | 1 | 24 AWG | 16 AWG | 300 VDC | 5.08 mm | 0.2 in | Surface Mount | |
 Phoenix Contact | Liquid Crystal Polymer (LCP) | Tin Plated | 10 A | Black | 10 | Vertical with Board | Leg Spring Push-In Spring | 1 | 24 AWG | 16 AWG | 300 VDC | 3.81 mm | 0.15 in | Surface Mount | |
 Phoenix Contact | Liquid Crystal Polymer (LCP) | Tin Plated | 10 A | Black | 11 | Horizontal with Board | Leg Spring Push-In Spring | 1 | 24 AWG | 16 AWG | 300 VDC | 3.81 mm | 0.15 in | Surface Mount | Board Guide |
 Phoenix Contact | Liquid Crystal Polymer (LCP) | Tin Plated | 10 A | Black | 5 | Horizontal with Board | Leg Spring Push-In Spring | 1 | 24 AWG | 16 AWG | 300 VDC | 3.81 mm | 0.15 in | Surface Mount | Board Guide |
 Phoenix Contact | 10 A | Black | 5 | Vertical with Board | Leg Spring Push-In Spring | 1 | 24 AWG | 16 AWG | 300 VDC | 3.81 mm | 0.15 in | Surface Mount | |||
 Phoenix Contact | Liquid Crystal Polymer (LCP) | Tin Plated | 10 A | Black | 12 | Horizontal with Board | Leg Spring Push-In Spring | 1 | 24 AWG | 16 AWG | 300 VDC | 5 mm | 0.197 in | Surface Mount | Board Guide |
