333-041 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 41POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions/Bay/Row | Termination | Card Type | Number of Positions | Contact Type | Mounting Type | Read Out | Pitch | Pitch | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Number of Rows | Gender | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 41 | Wire Wrap | Non Specified - Single Edge | 41 | Cantilever | Through Hole | Single | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | Gold | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | 41 | Solder | Non Specified - Single Edge | 41 | Cantilever | Through Hole | Single | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | Gold | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | 41 | Wire Wrap | Non Specified - Single Edge | 41 | Cantilever | Right Angle Through Hole | Single | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | Gold | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | 41 | Wire Wrap | Non Specified - Single Edge | 41 | Cantilever | Through Hole | Single | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | Gold | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | 41 | Solder | Non Specified - Single Edge | 41 | Cantilever | Through Hole | Single | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | Gold | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 41 | Wire Wrap | Non Specified - Single Edge | 41 | Cantilever | Through Hole | Single | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | Gold | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 41 | Solder | Non Specified - Single Edge | 41 | Cantilever | Through Hole | Single | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | Gold | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | 41 | Solder | Non Specified - Single Edge | 41 | Cantilever | Through Hole | Single | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | Gold | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | 41 | Solder | Non Specified - Single Edge | 41 | Cantilever | Through Hole | Single | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | Gold | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 41 | Wire Wrap | Non Specified - Single Edge | 41 | Cantilever | Through Hole | Single | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | Gold | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening |
