896-038 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 38POS 0.125
| Part | Termination Rows | Material - Insulation | Contact Finish | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Color | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Termination | Read Out | Contact Type | Flange Feature | Pitch | Pitch | Number of Positions | Number of Positions/Bay/Row [custom] | Number of Rows | Gender | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows [custom] | Number of Rows [custom] | Number of Positions/Bay/Row | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | Non Specified - Single Edge | 125 °C | -40 C | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Wire Wrap | Single | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | 3.18 mm | 0.125 in | 38 | 38 | 1 | Female | 0.25 Ám | 10 Áin | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | Non Specified - Single Edge | 125 °C | -40 C | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Solder Eyelet(s) | Single | Cantilever | Flush Mount Top Opening Unthreaded | 3.18 mm | 0.125 in | 38 | 38 | 1 | Female | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | Non Specified - Single Edge | 125 °C | -40 C | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Wire Wrap | Single | Cantilever | Side Mount Opening Unthreaded | 3.18 mm | 0.125 in | 38 | 38 | 1 | Female | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | Non Specified - Single Edge | 125 °C | -40 C | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Wire Wrap | Single | Cantilever | 3.18 mm | 0.125 in | 38 | 38 | 1 | Female | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | Non Specified - Single Edge | 125 °C | -40 C | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Wire Wrap | Single | Cantilever | Flush Mount M3 Threaded Insert Top Opening | 3.18 mm | 0.125 in | 38 | 38 | 1 | Female | 0.25 Ám | 10 Áin | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Gold | Non Specified - Dual Edge | 125 °C | -40 C | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Wire Wrap | Dual | Cantilever | Floating Bobbin Flush Mount | 3.18 mm | 0.125 in | 38 | Female | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | 2 | 2 | 19 | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | Non Specified - Single Edge | 125 °C | -40 C | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Solder | Single | Cantilever | Side Mount Opening Unthreaded | 3.18 mm | 0.125 in | 38 | 38 | 1 | Female | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Gold | Non Specified - Dual Edge | 125 °C | -40 C | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Solder | Dual | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | 3.18 mm | 0.125 in | 38 | Female | 0.25 Ám | 10 Áin | 2 | 2 | 19 | Card Extender | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Gold | Non Specified - Dual Edge | 125 °C | -40 C | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Solder | Dual | Cantilever | Flush Mount Top Opening Unthreaded | 3.18 mm | 0.125 in | 38 | Female | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 2 | 2 | 19 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Gold | Non Specified - Dual Edge | 125 °C | -40 C | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Solder | Dual | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | 3.18 mm | 0.125 in | 38 | Female | 0.25 Ám | 10 Áin | 2 | 2 | 19 |
