9916 Series

Catalog

HOOK-UP STRND 16AWG VIOLET

Part	Length	Length	Conductor Material	Wire Gauge	Ratings	Jacket Color	Voltage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Cable Type	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]
Belden Inc. 9916 0071000	304.8 m	1000 ft	Copper Tinned	16 AWG	UL Style 1007/1569	Violet	300 VDC	0.41 mm	0.016 in	Hook-Up	30 AWG	26	Poly-Vinyl Chloride (PVC)	0.092 "	2.34 mm
Belden Inc. 9916 002100			Copper Tinned	16 AWG	UL Style 1007/1569	Red	300 VDC	0.41 mm	0.016 in	Hook-Up	30 AWG	26	Poly-Vinyl Chloride (PVC)	0.092 "	2.34 mm	100 ft	30.5 m
Belden Inc. 9916 0105000			Copper Tinned	16 AWG	UL Style 1007/1569	Black	300 VDC	0.41 mm	0.016 in	Hook-Up	30 AWG	26	Poly-Vinyl Chloride (PVC)	0.092 "	2.34 mm
Belden Inc. 9916 009100			Copper Tinned	16 AWG	UL Style 1007/1569	White	300 VDC	0.41 mm	0.016 in	Hook-Up	30 AWG	26	Poly-Vinyl Chloride (PVC)	0.092 "	2.34 mm	100 ft	30.5 m
Belden Inc. 9916 0081000	304.8 m	1000 ft	Copper Tinned	16 AWG	UL Style 1007/1569	Gray	300 VDC	0.41 mm	0.016 in	Hook-Up	30 AWG	26	Poly-Vinyl Chloride (PVC)	0.092 "	2.34 mm
Belden Inc. 9916 0095000			Copper Tinned	16 AWG	UL Style 1007/1569	White	300 VDC	0.41 mm	0.016 in	Hook-Up	30 AWG	26	Poly-Vinyl Chloride (PVC)	0.092 "	2.34 mm
Belden Inc. 9916 0101000	304.8 m	1000 ft	Copper Tinned	16 AWG	UL Style 1007/1569	Black	300 VDC	0.41 mm	0.016 in	Hook-Up	30 AWG	26	Poly-Vinyl Chloride (PVC)	0.092 "	2.34 mm
Belden Inc. 9916 0051000	304.8 m	1000 ft	Copper Tinned	16 AWG	UL Style 1007/1569	Green	300 VDC	0.41 mm	0.016 in	Hook-Up	30 AWG	26	Poly-Vinyl Chloride (PVC)	0.092 "	2.34 mm
Belden Inc. 9916 0041000	304.8 m	1000 ft	Copper Tinned	16 AWG	UL Style 1007/1569	Yellow	300 VDC	0.41 mm	0.016 in	Hook-Up	30 AWG	26	Poly-Vinyl Chloride (PVC)	0.092 "	2.34 mm
Belden Inc. 9916 005100			Copper Tinned	16 AWG	UL Style 1007/1569	Green	300 VDC	0.41 mm	0.016 in	Hook-Up	30 AWG	26	Poly-Vinyl Chloride (PVC)	0.092 "	2.34 mm	100 ft	30.5 m
