1546310 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN BARRIER STRIP 3CIRC 0.563"
| Part | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Material - Insulation | Material Flammability Rating | Terminal Screw Material | Terminal Screw Finish | Terminal Block Type | Number of Wire Entries | Voltage Rating | Top Termination | Bottom Termination | Number of Circuits | Number of Rows [custom] | Wire Gauge [Max] | Wire Gauge [Min] | Barrier Type | Pitch | Pitch | Features | Color | Current Rating (Amps) | Number of Wire Entries [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Chassis Panel | 120 °C | -40 C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Steel | Nickel | Barrier Block | 6 | 300 VDC | Screws with Quick Connect Tabs | Closed | 3 | 2 | 22 AWG | 10 AWG | 2 Wall (Dual) | 14.3 mm | 0.563 " | Flange | Black | 30 A | |
 TE Connectivity AMP Connectors | Chassis Panel | 120 °C | -40 C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Steel | Nickel | Barrier Block | 8 | 300 VDC | Screws | Closed | 4 | 2 | 22 AWG | 10 AWG | 2 Wall (Dual) | 14.3 mm | 0.563 " | Flange | Black | 30 A | |
 TE Connectivity AMP Connectors | Chassis Panel | 120 °C | -40 C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Steel | Nickel | Barrier Block | 16 | 300 VDC | Screws | Closed | 8 | 2 | 22 AWG | 10 AWG | 2 Wall (Dual) | 14.3 mm | 0.563 " | Flange | Black | 30 A | |
 TE Connectivity AMP Connectors | Chassis Panel | 120 °C | -40 C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Brass | Nickel | Barrier Block | 12 | 300 VDC | Screws | Closed | 6 | 2 | 22 AWG | 10 AWG | 2 Wall (Dual) | 14.3 mm | 0.563 " | Flange | Black | 30 A | |
TE Connectivity AMP Connectors | Chassis Panel | 120 °C | -40 C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Steel | Nickel | Barrier Block | 12 | 300 VDC | Screws with Quick Connect Tabs | Closed | 6 | 2 | 22 AWG | 10 AWG | 2 Wall (Dual) | 14.3 mm | 0.563 " | Flange | Black | 30 A | |
 TE Connectivity AMP Connectors | Chassis Panel | 120 °C | -40 C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Steel | Nickel | Barrier Block | 20 | 300 VDC | Screws | Closed | 10 | 2 | 22 AWG | 10 AWG | 2 Wall (Dual) | 14.3 mm | 0.563 " | Flange | Black | 30 A | |
 TE Connectivity AMP Connectors | Chassis Panel | 120 °C | -40 C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Steel | Nickel | Barrier Block | 300 VDC | Screws | Closed | 18 | 2 | 22 AWG | 10 AWG | 2 Wall (Dual) | 14.3 mm | 0.563 " | Flange | Black | 30 A | 36 | |
TE Connectivity AMP Connectors | Chassis Panel | 120 °C | -40 C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Steel | Nickel | Barrier Block | 26 | 300 VDC | Screws | Closed | 13 | 2 | 22 AWG | 10 AWG | 2 Wall (Dual) | 14.3 mm | 0.563 " | Flange | Black | 30 A |
