X95820 Series

Catalog

DUAL DIGITAL CONTROLLED POTENTIOMETERS (XDCP™); LOW NOISE/LOW POWER/2-WIRE BUS/256 TAPS

Part	Voltage - Supply [Max]	Voltage - Supply [Min]	Configuration	Tolerance	Interface	Memory Type	Package / Case [x]	Package / Case	Supplier Device Package	Temperature Coefficient (Typ)	Operating Temperature [Max]	Operating Temperature [Min]	Resistance - Wiper (Ohms) (Typ)	Mounting Type	Taper	Features	Resistance (Ohms) [custom]	Number of Circuits	Number of Taps	Resistance (Ohms)
Renesas Electronics Corporation X95820UV14IZ-2.7T1	5.5 V	2.7 V	Potentiometer	20 %	I2C	Non-Volatile	0.173 " 4.4 mm	14-TSSOP	14-TSSOP	45 ppm/°C	85 °C	-40 C	70 Ohms	Surface Mount	Linear	Selectable Address	50 kOhms	2	256
Renesas Electronics Corporation X95820UV14I-2.7	5.5 V	2.7 V	Potentiometer	20 %	I2C	Non-Volatile	0.173 " 4.4 mm	14-TSSOP	14-TSSOP	45 ppm/°C	85 °C	-40 C	70 Ohms	Surface Mount	Linear	Selectable Address	50 kOhms	2	256
Renesas Electronics Corporation X95820WV14IZ-2.7	5.5 V	2.7 V	Potentiometer	20 %	I2C	Non-Volatile	0.173 " 4.4 mm	14-TSSOP	14-TSSOP	45 ppm/°C	85 °C	-40 C	70 Ohms	Surface Mount	Linear	Selectable Address		2	256	10k
Renesas Electronics Corporation X95820UV14IZ-2.7	5.5 V	2.7 V	Potentiometer	20 %	I2C	Non-Volatile	0.173 " 4.4 mm	14-TSSOP	14-TSSOP	45 ppm/°C	85 °C	-40 C	70 Ohms	Surface Mount	Linear	Selectable Address	50 kOhms	2	256
Renesas Electronics Corporation X95820WV14IZ-2.7T1	5.5 V	2.7 V	Potentiometer	20 %	I2C	Non-Volatile	0.173 " 4.4 mm	14-TSSOP	14-TSSOP	45 ppm/°C	85 °C	-40 C	70 Ohms	Surface Mount	Linear	Selectable Address		2	256	10k
