F221V3/64 Series

Catalog

HEATSHRINK 0.046" X 4' BLUE

Part	Operating Temperature [Max]	Operating Temperature [Min]	Recovered Wall Thickness	Recovered Wall Thickness	Material	Type	Shelf Life Start	Length [x]	Length [x]	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Shelf Life	Shrink Temperature	Shrinkage Ratio	Features	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Color	Length	Length
ALPHA WIRE F221V3/64 BL103	135 °C	-55 °C	0.016 "	0.41 mm	Polyolefin (PO) Irradiated	Tubing Flexible	Date of Manufacture	1.22 m	4 ft	1.17 mm	0.046 in	144 Months	90 °C	2 to 1	Flame Retardant Fluid Resistant Heat Resistant	0.023 in	0.58 mm	Blue
ALPHA WIRE F221V3/64 WH103	135 °C	-55 °C	0.016 "	0.41 mm	Polyolefin (PO) Irradiated	Tubing Flexible	Date of Manufacture	1.22 m	4 ft	1.17 mm	0.046 in	144 Months	90 °C	2 to 1	Flame Retardant Fluid Resistant Heat Resistant	0.023 in	0.58 mm	White
ALPHA WIRE F221V3/64 BK103	135 °C	-55 °C	0.016 "	0.41 mm	Polyolefin (PO) Irradiated	Tubing Flexible	Date of Manufacture	1.22 m	4 ft	1.17 mm	0.046 in	144 Months	90 °C	2 to 1	Flame Retardant Fluid Resistant Heat Resistant UV Resistant	0.023 in	0.58 mm	Black
ALPHA WIRE F221V3/64 BK205	135 °C	-55 °C	0.016 "	0.41 mm	Polyolefin (PO) Irradiated	Tubing Flexible	Date of Manufacture			1.17 mm	0.046 in	144 Months	90 °C	2 to 1	Flame Retardant Fluid Resistant Heat Resistant UV Resistant	0.023 in	0.58 mm	Black	1000 ft	304.8 m
