325-078 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 78POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Read Out | Contact Material | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Number of Positions | Termination | Contact Finish Thickness | Contact Finish Thickness | Color | Card Thickness | Card Thickness | Number of Positions/Bay/Row | Mounting Type | Contact Type | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch | Gender |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Copper Alloy | Gold | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | 2 | 78 | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Green | 3.18 mm | 0.125 in | 39 | Through Hole | Cantilever | Non Specified - Dual Edge | -65 ░C | 125 °C | 0.1 " | 2.54 mm | Female |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Copper Alloy | Gold | 2 | 78 | Solder | 0.25 Ám | 10 Áin | Green | 3.18 mm | 0.125 in | 39 | Through Hole | Cantilever | Non Specified - Dual Edge | -65 ░C | 125 °C | 0.1 " | 2.54 mm | Female | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Copper Alloy | Gold | Flush Mount M3 Threaded Insert Top Opening | 2 | 78 | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Green | 3.18 mm | 0.125 in | 39 | Through Hole | Cantilever | Non Specified - Dual Edge | -65 ░C | 125 °C | 0.1 " | 2.54 mm | Female | ||
EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Copper Alloy | Gold | Flush Mount M3 Threaded Insert Top Opening | 2 | 78 | Solder | 0.25 Ám | 10 Áin | Green | 3.18 mm | 0.125 in | 39 | Through Hole | Cantilever | Non Specified - Dual Edge | -65 ░C | 125 °C | 0.1 " | 2.54 mm | Female | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Copper Alloy | Gold | 2 | 78 | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Green | 3.18 mm | 0.125 in | 39 | Through Hole | Cantilever | Non Specified - Dual Edge | -65 ░C | 125 °C | 0.1 " | 2.54 mm | Female | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Copper Alloy | Gold | 4-40 Flush Mount Threaded Insert Top Opening | 2 | 78 | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Green | 3.18 mm | 0.125 in | 39 | Through Hole | Cantilever | Non Specified - Dual Edge | -65 ░C | 125 °C | 0.1 " | 2.54 mm | Female | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Copper Alloy | Gold | 2 | 78 | Wire Wrap | 0.25 Ám | 10 Áin | Green | 3.18 mm | 0.125 in | 39 | Through Hole | Cantilever | Non Specified - Dual Edge | -65 ░C | 125 °C | 0.1 " | 2.54 mm | Female | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Copper Alloy | Gold | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | 2 | 78 | Solder | 0.25 Ám | 10 Áin | Green | 3.18 mm | 0.125 in | 39 | Through Hole | Cantilever | Non Specified - Dual Edge | -65 ░C | 125 °C | 0.1 " | 2.54 mm | Female |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Copper Alloy | Gold | 4-40 Flush Mount Threaded Insert Top Opening | 2 | 78 | Solder | 0.25 Ám | 10 Áin | Green | 3.18 mm | 0.125 in | 39 | Through Hole | Cantilever | Non Specified - Dual Edge | -65 ░C | 125 °C | 0.1 " | 2.54 mm | Female |
