1328A Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 10CON 18AWG BLU
| Part | Shield Coverage | Shield Material | Jacket Color | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Shield Type | Conductor Strand [custom] | Conductor Strand [custom] | Voltage | Conductor Insulation | Conductor Insulation | Cable Type | Number of Conductors | Length | Length | Features | Jacket (Insulation) Material | Wire Gauge | Operating Temperature [Min] | Operating Temperature [Max] | Conductor Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum | Blue | 13.97 mm | 0.55 in | Foil | 26 AWG | 7 | 300 VDC | Polyolefin | PO | Multi-Pair | 10 | 304.8 m | 1000 ft | Drain Wire Rip Cord | Poly-Vinyl Chloride (PVC) | 18 AWG | -40 C | 105 ░C | Copper Tinned |
Belden Inc. | 100 % | Aluminum | Orange | 13.97 mm | 0.55 in | Foil | 26 AWG | 7 | 300 VDC | Polyolefin | PO | Multi-Pair | 10 | 304.8 m | 1000 ft | Drain Wire Rip Cord | Poly-Vinyl Chloride (PVC) | 18 AWG | -40 C | 105 ░C | Copper Tinned |
