PNF14 Series

Catalog

CONN SPADE TERM 14-16AWG #8 BLU

Part	Insulation Diameter [diameter]	Insulation Diameter [diameter]	Material - Insulation	Contact Finish	Features	Contact Material	Insulation	Mounting Type	Terminal Type	Wire Gauge [Min]	Wire Gauge [Max]	Color	Termination	Width - Outer Edges	Width - Outer Edges	Length - Overall [x]	Length - Overall [x]	Stud/Tab Size	Insulation Diameter [Max] [diameter]	Insulation Diameter [Min] [diameter]	Insulation Diameter [Min] [diameter]	Insulation Diameter [Max] [diameter]	Length - Overall	Length - Overall	Thickness	Thickness	Width - Outer Edges [x]	Width - Outer Edges [x]	Width - Outer Edges [y]	Width - Outer Edges [y]	Tongue Inside Opening	Tongue Inside Opening
Panduit Corp PNF14-8F-3K	4.11 mm	0.162 in	Nylon Polyamide (PA)	Tin	Serrated Termination	Copper	Insulated	Free Hanging (In-Line)	Standard	14 AWG	16 AWG	Blue	Crimp	7.87 mm	0.31 in	21.34 mm	0.84 in	8 Stud
Panduit Corp PNF14-14R-3K			Nylon Polyamide (PA)	Tin	Serrated Termination	Copper	Insulated	Free Hanging (In-Line)	Circular	14 AWG	16 AWG	Blue	Crimp					0.25 Stud	0.162 "	0.08 in	2.03 mm	4.11 mm	1.06 in	26.92 mm	0.79 mm	0.031 in	0.46 in	11.68 mm
Panduit Corp PNF14-10F-3K	4.11 mm	0.162 in	Nylon Polyamide (PA)	Tin	Serrated Termination	Copper	Insulated	Free Hanging (In-Line)	Standard	14 AWG	16 AWG	Blue	Crimp			21.84 mm	0.86 "	10 Stud											0.34 in	8.64 mm
Panduit Corp PNF14-10FF-3K			Nylon Polyamide (PA)	Tin	Serrated Termination	Copper	Insulated	Free Hanging (In-Line)	Flanged	14 AWG	16 AWG	Blue	Crimp			22.1 mm	0.87 in	10 Stud	0.162 "	0.08 in	2.03 mm	4.11 mm					0.35 in	8.89 mm			0.198 in	5.03 mm
Panduit Corp PNF14-14R-M			Nylon Polyamide (PA)	Tin	Serrated Termination	Copper	Insulated	Free Hanging (In-Line)	Circular	14 AWG	16 AWG	Blue	Crimp					0.25 Stud	0.162 "	0.087 in	2.21 mm	4.11 mm	1.06 in	26.92 mm	0.81 mm	0.032 in	0.46 in	11.68 mm
Panduit Corp PNF14-56R-M			Nylon Polyamide (PA)	Tin	Serrated Termination	Copper	Insulated	Free Hanging (In-Line)	Circular	14 AWG	16 AWG	Blue	Crimp					0.3125 Stud	0.162 "	0.087 in	2.21 mm	4.11 mm	1.06 in	26.92 mm	0.81 mm	0.032 in	0.46 in	11.68 mm
Panduit Corp PNF14-4R-C			Nylon Polyamide (PA)	Tin	Serrated Termination	Copper	Insulated	Free Hanging (In-Line)	Circular	14 AWG	16 AWG	Blue	Crimp			19.81 mm	0.78 in	4 Stud	0.162 "	0.087 in	2.21 mm	4.11 mm			0.81 mm	0.032 in	0.25 "	6.35 mm
Panduit Corp PNF14-6RN-C			Nylon Polyamide (PA)	Tin	Serrated Termination	Copper	Insulated	Free Hanging (In-Line)	Circular	14 AWG	16 AWG	Blue	Crimp			19.81 mm	0.78 in	6 Stud	0.162 "	0.087 in	2.21 mm	4.11 mm			0.81 mm	0.032 in	0.25 "	6.35 mm
Panduit Corp PNF14-38R-M			Nylon Polyamide (PA)	Tin	Serrated Termination	Copper	Insulated	Free Hanging (In-Line)	Circular	14 AWG	16 AWG	Blue	Crimp	13.46 mm	0.53 in	28.96 mm	1.14 in	0.375 Stud	0.162 "	0.087 in	2.21 mm	4.11 mm			0.81 mm	0.032 in
Panduit Corp PNF14-6R-M			Nylon Polyamide (PA)	Tin	Serrated Termination	Copper	Insulated	Free Hanging (In-Line)	Circular	14 AWG	16 AWG	Blue	Crimp	7.87 mm	0.31 in	22.1 mm	0.87 in	6 Stud	0.162 "	0.087 in	2.21 mm	4.11 mm			0.81 mm	0.032 in
