896-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 9POS 0.125
| Part | Termination Rows | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Contact Finish | Number of Positions | Contact Type | Number of Positions/Bay/Row | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Gender | Card Type | Termination | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Contact Material | Number of Rows | Read Out |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Gold | 9 | Cantilever | 9 | Black | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Female | Non Specified - Single Edge | Solder | 0.25 Ám | 10 Áin | Right Angle Through Hole | Copper Alloy | 1 | Single |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Gold | 9 | Cantilever | 9 | Black | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Female | Non Specified - Single Edge | Wire Wrap | 0.25 Ám | 10 Áin | Through Hole | Copper Alloy | 1 | Single |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Gold | 9 | Cantilever | 9 | Black | M3 Threaded Insert Top Mount Opening | Female | Non Specified - Single Edge | Solder | 0.25 Ám | 10 Áin | Right Angle Through Hole | Copper Alloy | 1 | Single | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Gold | 9 | Cantilever | 9 | Black | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Female | Non Specified - Single Edge | Wire Wrap | 0.25 Ám | 10 Áin | Through Hole | Copper Alloy | 1 | Single |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Gold | 9 | Cantilever | 9 | Black | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Female | Non Specified - Single Edge | Wire Wrap | 0.25 Ám | 10 Áin | Through Hole | Copper Alloy | 1 | Single |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Gold | 9 | Cantilever | 9 | Black | 0.128 " | 3.25 mm | Female | Non Specified - Single Edge | Solder | 0.25 Ám | 10 Áin | Right Angle Through Hole | Copper Alloy | 1 | Single | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Gold | 9 | Cantilever | 9 | Black | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Female | Non Specified - Single Edge | Solder | 0.25 Ám | 10 Áin | Right Angle Through Hole | Copper Alloy | 1 | Single |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Gold | 9 | Cantilever | 9 | Black | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Female | Non Specified - Single Edge | Solder | 0.25 Ám | 10 Áin | Through Hole | Copper Alloy | 1 | Single |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Gold | 9 | Cantilever | 9 | Black | 4-40 Flush Mount Threaded Insert Top Opening | Female | Non Specified - Single Edge | Solder | 0.25 Ám | 10 Áin | Right Angle Through Hole | Copper Alloy | 1 | Single | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Gold | 9 | Cantilever | 9 | Black | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Female | Non Specified - Single Edge | Solder | 0.25 Ám | 10 Áin | Right Angle Through Hole | Copper Alloy | 1 | Single |
