45226 Series
Manufacturer: 3M (TC)
Beta
⌘K
26P HDR SMT 30AU T&R
| Part | Pitch - Mating | Pitch - Mating | Features | Style | Voltage Rating | Row Spacing - Mating | Row Spacing - Mating | Insulation Material | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Number of Positions Loaded | Connector Type | Material Flammability Rating | Mounting Type | Number of Positions | Insulation Height | Insulation Height | Shrouding | Contact Type | Contact Shape | Fastening Type | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Number of Rows | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish - Post | Termination | Contact Finish - Mating | Contact Finish Thickness - Mating | Contact Length - Post | Contact Length - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
3M (TC) | 0.05 in | 1.27 mm | Keying Slot Pick and Place | Board to Cable/Wire | 125 VAC | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | 3 µin | 0.076 µm | All | Header | UL94 V-0 | Surface Mount | 26 | 0.222 " | 5.64 mm | Shrouded - 4 Wall | Male Pin | Square | Push-Pull | 200 µin | 5.08 µm | 2 | Copper Alloy | 125 °C | -65 ░C | Tin | Solder | Gold | |||
3M (TC) | 0.05 in | 1.27 mm | Keying Slot Pick and Place | Board to Cable/Wire | 125 VAC | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | All | Header | UL94 V-0 | Surface Mount | 26 | 0.222 " | 5.64 mm | Shrouded - 4 Wall | Male Pin | Square | Latch Lock/Eject Hooks Short | 100 µin | 2.54 µm | 2 | Copper Alloy | 125 °C | -65 ░C | Tin | Solder | Gold | Flash | ||||
 3M (TC) | 0.05 in | 1.27 mm | Keying Slot | Board to Cable/Wire | 125 VAC | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | 3 µin | 0.076 µm | All | Header | UL94 V-0 | Through Hole | 26 | 0.222 " | 5.64 mm | Shrouded - 4 Wall | Male Pin | Square | Push-Pull | 200 µin | 5.08 µm | 2 | Copper Alloy | 125 °C | -65 ░C | Tin | Solder | Gold | 0.094 in | 2.4 mm | |
 3M (TC) | 0.05 in | 1.27 mm | Keying Slot | Board to Cable/Wire | 125 VAC | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | All | Header | UL94 V-0 | Through Hole Right Angle | 26 | 0.21 in | 5.33 mm | Shrouded - 4 Wall | Male Pin | Square | Latch Lock/Eject Hooks Short | 100 µin | 2.54 µm | 2 | Copper Alloy | 125 °C | -65 ░C | Tin | Solder | Gold | Flash | 0.094 in | 2.4 mm | ||
 3M (TC) | 0.05 in | 1.27 mm | Keying Slot | Board to Cable/Wire | 125 VAC | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | 3 µin | 0.076 µm | All | Header | UL94 V-0 | Through Hole Right Angle | 26 | 0.21 in | 5.33 mm | Shrouded - 4 Wall | Male Pin | Square | Latch Lock/Eject Hooks Short | 200 µin | 5.08 µm | 2 | Copper Alloy | 125 °C | -65 ░C | Tin | Solder | Gold | 0.094 in | 2.4 mm | |
 3M (TC) | 0.05 in | 1.27 mm | Keying Slot | Board to Cable/Wire | 125 VAC | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | 3 µin | 0.076 µm | All | Header | UL94 V-0 | Through Hole Right Angle | 26 | 0.21 in | 5.33 mm | Shrouded - 4 Wall | Male Pin | Square | Push-Pull | 200 µin | 5.08 µm | 2 | Copper Alloy | 125 °C | -65 ░C | Tin | Solder | Gold | 0.094 in | 2.4 mm | |
 3M (TC) | 0.05 in | 1.27 mm | Keying Slot | Board to Cable/Wire | 125 VAC | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | All | Header | UL94 V-0 | Through Hole | 26 | 0.222 " | 5.64 mm | Shrouded - 4 Wall | Male Pin | Square | Latch Lock/Eject Hooks Short | 100 µin | 2.54 µm | 2 | Copper Alloy | 125 °C | -65 ░C | Tin | Solder | Gold | Flash | 0.094 in | 2.4 mm | ||
 3M (TC) | 0.05 in | 1.27 mm | Keying Slot | Board to Cable/Wire | 125 VAC | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | All | Header | UL94 V-0 | Through Hole Right Angle | 26 | 0.21 in | 5.33 mm | Shrouded - 4 Wall | Male Pin | Square | Push-Pull | 100 µin | 2.54 µm | 2 | Copper Alloy | 125 °C | -65 ░C | Tin | Solder | Gold | Flash | 0.094 in | 2.4 mm | ||
3M (TC) | 0.05 in | 1.27 mm | Keying Slot Pick and Place | Board to Cable/Wire | 125 VAC | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | All | Header | UL94 V-0 | Surface Mount | 26 | 0.222 " | 5.64 mm | Shrouded - 4 Wall | Male Pin | Square | Push-Pull | 100 µin | 2.54 µm | 2 | Copper Alloy | 125 °C | -65 ░C | Tin | Solder | Gold | Flash | ||||
 3M (TC) | 0.05 in | 1.27 mm | Keying Slot | Board to Cable/Wire | 125 VAC | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | All | Header | UL94 V-0 | Through Hole | 26 | 0.222 " | 5.64 mm | Shrouded - 4 Wall | Male Pin | Square | Push-Pull | 100 µin | 2.54 µm | 2 | Copper Alloy | 125 °C | -65 ░C | Tin | Solder | Gold | Flash | 0.094 in | 2.4 mm |
