12TL1 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH TOGGLE DPDT 15A 125V
| Part | Actuator Material | Operating Temperature [Min] | Operating Temperature [Max] | Ingress Protection | Actuator Length [x] | Switch Function | Voltage Rating - AC | Bushing Thread | Illumination | Circuit | Termination Style | Actuator Type | Current Rating (Amps) | Mounting Type | Panel Cutout Dimensions [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Environment Sealed | 26.67 mm | On-Off-On | 125 V | 15/32-32 | Non-Illuminated | DPDT | Solder Turret | Locking Lever | 15 A | Panel Mount | 12.4 mm | |
Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Environment Sealed | 26.67 mm | On-Off | 125 V | 15/32-32 | Non-Illuminated | DPST | Solder Turret | Locking Lever | 15 A | Panel Mount | 12.4 mm | |
 Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Environment Sealed | 17.27 mm | On-Mom | 125 V | 15/32-32 | Non-Illuminated | DPDT | Solder Turret | Standard Round | 10 A | Panel Mount | 12.4 mm | |
Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Environment Sealed | 17.27 mm | On-On-On | 125 V | 15/32-32 | Non-Illuminated | SP3T | Solder Turret | Standard Round | 15 A | Panel Mount | 12.4 mm | Jumper needed to achieve triple throw |
Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Environment Sealed | 17.27 mm | Mom-On-Mom | 125 V | 15/32-32 | Non-Illuminated | DPDT | Solder Turret | Standard Round | 10 A | Panel Mount | 12.4 mm | |
 Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Environment Sealed | 17.27 mm | On-Off | 125 V | 15/32-32 | Non-Illuminated | DPST | Solder Turret | Standard Round | 15 A | Panel Mount | 12.4 mm | |
Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Environment Sealed | 26.67 mm | On-On | 125 V | 15/32-32 | Non-Illuminated | DPDT | Solder Turret | Locking Lever | 15 A | Panel Mount | 12.4 mm | |
 Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Environment Sealed | 17.27 mm | On-On | 125 V | 15/32-32 | Non-Illuminated | DPDT | Solder Turret | Standard Round | 15 A | Panel Mount | 12.4 mm |
