D2410 Series

Catalog

SSR RELAY SPST-NO 10A 24-280V

Part	Voltage - Input [Min]	Voltage - Input [Max]	Voltage - Load [Min]	Voltage - Load [Max]	Load Current	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Approval Agency	Termination Style	Output Type	Termination Style	Circuit
Sensata-Crydom D2410K	3 V	32 VDC	24 V	280 V	10 A	Chassis Mount	80 °C	-40 C	Hockey Puck	CE CSA TUV UL	Screw Terminal	AC Zero Cross
Sensata-Crydom D2410G-B	3 V	32 VDC	24 V	140 V	10 A	Chassis Mount	80 °C	-40 C	Hockey Puck	CE CSA TUV UL	Screw Terminal	AC Zero Cross
Sensata-Crydom D2410K-10	3 V	32 VDC	24 V	280 V	10 A	Chassis Mount	80 °C	-40 C	Hockey Puck	CE CSA TUV UL	Screw Terminal	AC
Sensata-Crydom D2410PG	3 V	32 VDC	24 V	280 V	10 A	Chassis Mount	80 °C	-40 C	Hockey Puck	CE CSA TUV UL	Screw Terminal	AC Zero Cross
Sensata-Crydom D2410FPG-10	3 V	32 VDC	24 V	280 V	10 A	Chassis Mount	80 °C	-40 C	Hockey Puck	CE CSA TUV UL	Quick Connect	AC	0.187 in 0.25 in
Sensata-Crydom D2410P	3 V	32 VDC	24 V	280 V	10 A	Chassis Mount	80 °C	-40 C	Hockey Puck	CE CSA TUV UL	Screw Terminal	AC Zero Cross
Sensata-Crydom D2410-10	3 V	32 VDC	24 V	280 V	10 A	Chassis Mount	80 °C	-40 C	Hockey Puck	CE CSA TUV UL	Screw Terminal	AC
Sensata-Crydom D2410-B	3 V	32 VDC	24 V	280 V	10 A	Chassis Mount	80 °C	-40 C	Hockey Puck	CE CSA TUV UL	Screw Terminal	AC Zero Cross		SPST-NC (1 Form B)
Sensata-Crydom D2410T	3 V	32 VDC	24 V	280 V	10 A	Chassis Mount	80 °C	-40 C	Hockey Puck	CE CSA TUV UL	Screw Terminal	AC Zero Cross
