NHD-10.1 Series

Catalog

10.1HDMI CAP USB-HID TOUCH&AUDIO

Part	Display Type	Display Mode	Backlight	Touchscreen	Interface	Viewing Area [y]	Viewing Area [x]	Dot Pixels [y]	Dot Pixels [x]	Diagonal Screen Size	Diagonal Screen Size	Graphics Color	Controller Type
Newhaven Display Intl NHD-10.1-HDMI-A-RSXV-CTU	TFT - Color	Transmissive	LED - White	Capacitive	HDMI	125.28 mm	222.72 mm	600	1024	10.1 in	256.54 mm	Blue Green Red	ADV7611
Newhaven Display Intl NHD-10.1-1024600MB-LSXV	TFT - Color	Transmissive	LED - White		LVDS	125.28 mm	222.72 mm	600	1024	10.1 in	256.54 mm	Blue Green Red	HX8282-A
Newhaven Display Intl NHD-10.1-HDMI-A-RSXV	TFT - Color	Transmissive	LED - White		HDMI	125.28 mm	222.72 mm	600	1024	10.1 in	256.54 mm	Blue Green Red	ADV7611
Newhaven Display Intl NHD-10.1-1024600MB-LSXV-CTP	TFT - Color	Transmissive	LED - White	Capacitive	LVDS	125.28 mm	222.72 mm	600	1024	10.1 in	256.54 mm	Blue Green Red	FT5526EEZ HX8282-A
