857-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 28POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Termination | Number of Positions/Bay/Row | Contact Type | Read Out | Mounting Type | Card Type | Number of Positions | Number of Rows [custom] | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Gender | Color | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Wire Wrap | 14 | Semi Bellows | Dual | Through Hole | Non Specified - Dual Edge | 28 | 2 | Copper Alloy | 125 °C | -40 C | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Female | Black | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Solder | 28 | Semi Bellows | Dual | Right Angle Through Hole | Non Specified - Dual Edge | 56 | 2 | Copper Alloy | 125 °C | -40 C | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Female | Black | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | 28 | Semi Bellows | Single | Right Angle Through Hole | Non Specified - Single Edge | 28 | Copper Alloy | 125 °C | -40 C | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Female | Black | 1 | 1 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Solder | 14 | Semi Bellows | Dual | Board Edge Straddle Mount | Non Specified - Dual Edge | 28 | 2 | Copper Alloy | 125 °C | -40 C | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Female | Black | Card Extender | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | 28 | Semi Bellows | Dual | Through Hole | Non Specified - Dual Edge | 56 | 2 | Copper Alloy | 125 °C | -40 C | 3.96 mm | 0.156 in | Female | Black | 1 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | 28 | Semi Bellows | Single | Right Angle Through Hole | Non Specified - Single Edge | 28 | Copper Alloy | 125 °C | -40 C | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Female | Black | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Solder | 28 | Semi Bellows | Single | Right Angle Through Hole | Non Specified - Single Edge | 28 | Copper Alloy | 125 °C | -40 C | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Female | Black | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Solder | 14 | Semi Bellows | Dual | Board Edge Straddle Mount | Non Specified - Dual Edge | 28 | 2 | Copper Alloy | 125 °C | -40 C | 3.96 mm | 0.156 in | Female | Black | Card Extender | |||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder Eyelet(s) | 28 | Semi Bellows | Single | Through Hole | Non Specified - Single Edge | 28 | Copper Alloy | 125 °C | -40 C | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Female | Black | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Wire Wrap | 14 | Semi Bellows | Dual | Through Hole | Non Specified - Dual Edge | 28 | 2 | Copper Alloy | 125 °C | -40 C | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Female | Black |
