857-038 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 38POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Color | Card Type | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Read Out | Termination | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Positions/Bay/Row | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Contact Type | Contact Material | Features | Number of Rows [custom] | Gender | Number of Positions/Bay/Row [custom] | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Dual | Solder | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 19 | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 38 | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Card Extender | 2 | Female | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Single | Solder | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 38 | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Female | 38 | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Single | Solder | Flush Mount M3 Threaded Insert Top Opening | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 38 | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Female | 38 | 1 | 1 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Dual | Solder | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 76 | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | 2 | Female | 38 | 1 | |||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Single | Wire Wrap | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 38 | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Female | 38 | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Single | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 38 | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Female | 38 | 1 | 1 | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Single | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 19 | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 38 | 125 °C | -40 C | Tin | Semi Bellows | Copper Alloy | 2 | Female | ||||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Dual | Solder | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 76 | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | 2 | Female | 38 | 1 | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Dual | Solder | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 19 | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 38 | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Card Extender | 2 | Female | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Single | Solder | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 38 | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Female | 38 | 1 | 1 |
