83001 Series

Catalog

HOOK-UP STRND 28AWG YELLOW

Part	Jacket (Insulation) Material	Ratings	Wire Gauge	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket Color	Conductor Material	Voltage	Conductor Strand [custom]	Conductor Strand [custom]	Features	Length	Length	Cable Type	Qualification	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]	Operating Temperature
Belden Inc. 83001 0041000	Polytetrafluoroethylene (PTFE)	UL Style 1213	28 AWG	0.25 mm	0.01 in	Yellow	Copper Silver Coated	600 V	7	36 AWG	High Temperature	304.8 m	1000 ft	Hook-Up	MIL-W-16878/4	0.035 in	0.89 mm
Belden Inc. 83001 007100	Polytetrafluoroethylene (PTFE)	UL Style 1213	28 AWG	0.25 mm	0.01 in	Violet	Copper Silver Coated	600 V	7	36 AWG	High Temperature			Hook-Up	MIL-W-16878/4	0.035 in	0.89 mm	100 ft	30.5 m	200 °C
Belden Inc. 83001 0071000	Polytetrafluoroethylene (PTFE)	UL Style 1213	28 AWG	0.25 mm	0.01 in	Violet	Copper Silver Coated	600 V	7	36 AWG	High Temperature	304.8 m	1000 ft	Hook-Up	MIL-W-16878/4	0.035 in	0.89 mm
Belden Inc. 83001 008100	Polytetrafluoroethylene (PTFE)	UL Style 1213	28 AWG	0.25 mm	0.01 in	Gray	Copper Silver Coated	600 V	7	36 AWG	High Temperature			Hook-Up	MIL-W-16878/4	0.035 in	0.89 mm	100 ft	30.5 m	200 °C
Belden Inc. 83001 0101000	Polytetrafluoroethylene (PTFE)	UL Style 1213	28 AWG	0.25 mm	0.01 in	Black	Copper Silver Coated	600 V	7	36 AWG	High Temperature	304.8 m	1000 ft	Hook-Up	MIL-W-16878/4	0.035 in	0.89 mm
Belden Inc. 83001 010100	Polytetrafluoroethylene (PTFE)	UL Style 1213	28 AWG	0.25 mm	0.01 in	Black	Copper Silver Coated	600 V	7	36 AWG	High Temperature			Hook-Up	MIL-W-16878/4	0.035 in	0.89 mm	100 ft	30.5 m
Belden Inc. 83001 003100	Polytetrafluoroethylene (PTFE)	UL Style 1213	28 AWG	0.25 mm	0.01 in	Orange	Copper Silver Coated	600 V	7	36 AWG	High Temperature			Hook-Up	MIL-W-16878/4	0.035 in	0.89 mm	100 ft	30.5 m	200 °C
Belden Inc. 83001 006100	Polytetrafluoroethylene (PTFE)	UL Style 1213	28 AWG	0.25 mm	0.01 in	Blue	Copper Silver Coated	600 V	7	36 AWG	High Temperature			Hook-Up	MIL-W-16878/4	0.035 in	0.89 mm	100 ft	30.5 m	200 °C
Belden Inc. 83001 001100	Polytetrafluoroethylene (PTFE)	UL Style 1213	28 AWG	0.25 mm	0.01 in	Brown	Copper Silver Coated	600 V	7	36 AWG	High Temperature			Hook-Up	MIL-W-16878/4	0.035 in	0.89 mm	100 ft	30.5 m	200 °C
Belden Inc. 83001 0021000	Polytetrafluoroethylene (PTFE)	UL Style 1213	28 AWG	0.25 mm	0.01 in	Red	Copper Silver Coated	600 V	7	36 AWG	High Temperature	304.8 m	1000 ft	Hook-Up	MIL-W-16878/4	0.035 in	0.89 mm
