CQB75W14 Series

Manufacturer: Cincon Electronics Co. LTD

Catalog

ISOLATED DC/DC CONVERTERS - CHASSIS MOUNT 75W 12-160VIN 12VOUT 6.3A INSERT + BUS

Part	Applications	Approval Agency	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Efficiency	Type	Voltage - Output 1	Current - Output (Max) [Max]	Control Features	Standard Number	Number of Outputs	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Features	Supplier Device Package	Power (Watts)	Package / Case	Voltage - Input (Max) [Max]	Voltage - Isolation	Voltage - Input (Min) [Min]
Cincon Electronics Co. LTD CQB75W14-72S12-C-B	ITE (Commercial)	CB CE cURus UKCA	105 C	-40 °C	Through Hole	88 %	Isolated Module	12 V	6.3 A	Active High Enable	62368-1	1	57.9 mm	1.45 in	0.5 in	2.28 "	12.7 mm	36.8 mm	Adjustable Output Remote On/Off	Quarter Brick	76 W	Quarter Brick	160 V	3000 V	12 V
Cincon Electronics Co. LTD CQB75W14-72S12-C	ITE (Commercial)	CB CE cURus UKCA	105 C	-40 °C	Through Hole	88 %	Isolated Module	12 V	6.3 A	Active High Enable	62368-1	1	57.9 mm	1.45 in	0.5 in	2.28 "	12.7 mm	36.8 mm	Adjustable Output Remote On/Off	Quarter Brick	76 W	Quarter Brick	160 V	3000 V	12 V
Cincon Electronics Co. LTD CQB75W14-72S05	ITE (Commercial)	CB CE cURus UKCA	105 C	-40 °C	Through Hole	89 %	Isolated Module	5 V	15 A	Active High Enable	62368-1	1	57.9 mm	1.45 in	0.5 in	2.28 "	12.7 mm	36.8 mm	Adjustable Output Remote On/Off	Quarter Brick	75 W	Quarter Brick	160 V	3000 V	12 V
Cincon Electronics Co. LTD CQB75W14-72S28-C	ITE (Commercial)	CB CE cURus UKCA	105 C	-40 °C	Through Hole	91 %	Isolated Module	28 V	2.7 A	Active High Enable	62368-1	1	57.9 mm	1.45 in	0.5 in	2.28 "	12.7 mm	36.8 mm	Adjustable Output Remote On/Off	Quarter Brick	76 W	Quarter Brick	160 V	3000 V	12 V
Cincon Electronics Co. LTD CQB75W14-72S28-C-B	ITE (Commercial)	CB CE cURus UKCA	105 C	-40 °C	Through Hole	91 %	Isolated Module	28 V	2.7 A	Active High Enable	62368-1	1	57.9 mm	1.45 in	0.5 in	2.28 "	12.7 mm	36.8 mm	Adjustable Output Remote On/Off	Quarter Brick	76 W	Quarter Brick	160 V	3000 V	12 V
