172-025 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG 25P PNL MNT SLDR
| Part | Dielectric Material | Color | Operating Temperature [Max] | Operating Temperature [Min] | Connector Style | Current Rating (Amps) | Number of Positions | Termination | Mounting Type | Flange Feature | Contact Finish | Material Flammability Rating | Contact Type | Connector Type | Number of Rows [custom] | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Contact Finish Thickness | Features | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Wire Gauge [Min] | Wire Gauge [Max] | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Black | 100 °C | -50 °C | D-Sub | 5 A | 25 | Solder | Panel Mount Through Hole | Housing/Shell (Unthreaded) | Gold | UL94 V-0 | Signal | Plug Male Pins | 2 | B DB | 3 | Flash | Grounding Indents | |||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | D-Sub | 5 A | 25 | Solder | Panel Mount Through Hole | Board Side (4-40) | Gold | UL94 V-0 | Signal | Plug Male Pins | 2 | B DB | 3 | Flash | Steel | Yellow Chromate Plated | |||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) Glass Filled | Beige | 100 °C | -50 °C | D-Sub | 5 A | 25 | Panel Mount | Cable Side (4-40) | Gold | UL94 V-0 | Signal | Receptacle Female Sockets | 2 | B DB | 3 | Flash | 19.5 AWG | 26 AWG | Brass | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) Polyester | Beige | 100 °C | -50 °C | D-Sub | 5 A | 25 | Solder | Panel Mount Through Hole | Board Side (4-40) | Gold | UL94 V-0 | Signal | Plug Male Pins | 2 | B DB | 3 | Flash | Grounding Indents | Brass | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Beige | 100 °C | -50 °C | D-Sub | 5 A | 25 | Wire Wrap | Panel Mount Through Hole | Housing/Shell (Unthreaded) | Gold | UL94 V-0 | Signal | Receptacle Female Sockets | 2 | B DB | 3 | Flash | Steel | Yellow Chromate Plated | ||||
NorComp Inc. | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | D-Sub | 5 A | 25 | Solder | Panel Mount Through Hole | Housing/Shell (Unthreaded) | Gold | UL94 V-0 | Signal | Plug Male Pins | 2 | B DB | 3 | Flash | Grounding Indents | ||||||
NorComp Inc. | Polybutylene Terephthalate (PBT) | Black | 100 °C | -50 °C | D-Sub | 5 A | 25 | Solder | Panel Mount Through Hole | Housing/Shell (Unthreaded) | Gold | UL94 V-0 | Signal | Plug Male Pins | 2 | B DB | 3 | Flash | Steel | Yellow Chromate Plated | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) Glass Filled | Beige | 100 °C | -50 °C | D-Sub | 5 A | 25 | Panel Mount | Housing/Shell (Unthreaded) | Gold | UL94 V-0 | Signal | Receptacle Female Sockets | 2 | B DB | 3 | Flash | 19.5 AWG | 26 AWG | Brass | ||||
NorComp Inc. | Polybutylene Terephthalate (PBT) | 125 °C | -50 °C | D-Sub | 5 A | 25 | Solder | Panel Mount Through Hole | Board Side (4-40) | Gold | UL94 V-0 | Signal | Plug Male Pins | 2 | B DB | 3 | Flash | Steel | Yellow Chromate Plated | |||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) Glass Filled | Beige | 100 °C | -50 °C | D-Sub | 5 A | 25 | Panel Mount | 4-40 | Gold | UL94 V-0 | Signal | Plug Male Pins | 2 | B DB | 3 | Flash | Grounding Indents | 19.5 AWG | 26 AWG | Brass |
