C180 Series

Catalog

SCR 300V 235A TO93

Part	Voltage - On State (Vtm) (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Current - Off State (Max) [Max] [custom]	Current - On State (It (AV)) (Max) [Max]	Current - Gate Trigger (Igt) (Max) [Max]	Current - On State (It (RMS)) (Max) [Max]	SCR Type	Package / Case	Current - Non Rep. Surge 50, 60Hz (Itsm)	Voltage - Off State	Current - On State (It (RMS)) (Max)
Powerex Inc. C180C	2.85 V	125 °C	-40 C	Chassis Stud Mount	20 mA	150 A	150 mA	235 A	Standard Recovery	Stud TO-209AB TO-93-4	3200 A 3500 A	300 V
Powerex Inc. C180PC	2.85 V	125 °C	-40 C	Chassis Stud Mount	20 mA	150 A	150 mA	235 A	Standard Recovery	Stud TO-209AB TO-93-4	3200 A 3500 A	1.3 kV
Powerex Inc. C180PB	2.85 V	125 °C	-40 C	Chassis Stud Mount	20 mA	150 A	150 mA	235 A	Standard Recovery	Stud TO-209AB TO-93-4	3200 A 3500 A	1.2 kV
Powerex Inc. C180N	2.85 V	125 °C	-40 C	Chassis Stud Mount	20 mA	150 A	150 mA	235 A	Standard Recovery	Stud TO-209AB TO-93-4	3200 A 3500 A	800 V
Powerex Inc. C180D	2.85 V	125 °C	-40 C	Chassis Stud Mount	20 mA	150 A	150 mA	235 A	Standard Recovery	Stud TO-209AB TO-93-4	3200 A 3500 A	400 V
Powerex Inc. C180MX500	2.85 V	125 °C	-40 C	Chassis Stud Mount	20 mA		150 mA		Standard Recovery	Stud TO-209AB TO-93-4	5000 A 5500 A	600 V	300 A
