845-076 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 76POS 0.100
...
| Part | Card Type | Material - Insulation | Number of Positions | Contact Finish | Number of Rows | Contact Type | Termination Rows | Gender | Termination | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Pitch [x] | Pitch [x] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Color | Number of Positions/Bay/Row [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Material | Flange Feature | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Non Specified - Dual Edge | Diallyl Phthalate (DAP) | 76 | Gold | 2 | Cantilever | 2 | Female | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Green | 38 | 125 °C | -40 °C | Dual | 0.156 in | Top Mount Opening Unthreaded | 3.96 mm | Copper Alloy | |||
 EDAC Inc. | Non Specified - Dual Edge | Diallyl Phthalate (DAP) | 76 | Gold | 2 | Cantilever | 2 | Female | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Board Edge Straddle Mount | 10 Áin | 0.25 Ám | Green | 38 | 125 °C | -40 °C | Dual | Copper Alloy | 3.25 mm | 0.128 in | Card Extender | |||
 EDAC Inc. | Non Specified - Dual Edge | Diallyl Phthalate (DAP) | 76 | Gold | 2 | Cantilever | 2 | Female | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Board Edge Straddle Mount | 10 Áin | 0.25 Ám | Green | 38 | 125 °C | -40 °C | Dual | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Copper Alloy | Card Extender | ||
 EDAC Inc. | Non Specified - Dual Edge | Diallyl Phthalate (DAP) | 76 | Gold | 2 | Cantilever | 2 | Female | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Board Edge Straddle Mount | 10 Áin | 0.25 Ám | Green | 38 | 125 °C | -40 °C | Dual | 0.156 in | Flush Mount Top Opening Unthreaded | 3.96 mm | Copper Alloy | Card Extender | ||
 EDAC Inc. | Non Specified - Dual Edge | Diallyl Phthalate (DAP) | 76 | Gold | 2 | Cantilever | 2 | Female | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Green | 38 | 125 °C | -40 °C | Dual | 0.116 in | Floating Bobbin Flush Mount | 2.95 mm | Copper Alloy | |||
 EDAC Inc. | Non Specified - Dual Edge | Diallyl Phthalate (DAP) | 76 | Gold | 2 | Cantilever | 2 | Female | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Green | 38 | 125 °C | -40 °C | Dual | Copper Alloy | 3.25 mm | 0.128 in | ||||
 EDAC Inc. | Non Specified - Dual Edge | Diallyl Phthalate (DAP) | 76 | Gold | 2 | Cantilever | 2 | Female | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Green | 38 | 125 °C | -40 °C | Dual | M3 Threaded Insert Top Mount Opening | Copper Alloy | |||||
 EDAC Inc. | Non Specified - Dual Edge | Diallyl Phthalate (DAP) | 76 | Gold | 2 | Cantilever | 2 | Female | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Green | 38 | 125 °C | -40 °C | Dual | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | |||||
 EDAC Inc. | Non Specified - Dual Edge | Diallyl Phthalate (DAP) | 76 | Gold | 2 | Cantilever | 2 | Female | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Green | 38 | 125 °C | -40 °C | Dual | M3 Threaded Insert Top Mount Opening | Copper Alloy | |||||
 EDAC Inc. | Non Specified - Dual Edge | Diallyl Phthalate (DAP) | 76 | Gold | 2 | Cantilever | 2 | Female | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Board Edge Straddle Mount | 10 Áin | 0.25 Ám | Green | 38 | 125 °C | -40 °C | Dual | 0.116 in | Floating Bobbin Top Mount Opening | 2.95 mm | Copper Alloy | Card Extender |
