M80-550 Series

Catalog

5+5 POS. MALE DIL HORIZONTAL THROUGHBOARD CONN. NO JACKSCREWS ROHS COMPLIANT: YES

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Shrouding	Contact Type	Number of Rows [custom]	Contact Shape	Contact Finish - Mating	Current Rating (Amps)	Insulation Height	Insulation Height	Contact Finish - Post	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions	Row Spacing - Mating	Row Spacing - Mating	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Contact Material	Voltage Rating	Pitch - Mating	Pitch - Mating	Features	Contact Length - Post	Contact Length - Post	Termination	Insulation Color	Connector Type	Mounting Type	Style	Fastening Type	Number of Positions Loaded	Material Flammability Rating	Insulation Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Number of Positions [custom]	Insulation Height [z]	Insulation Height [z]
Harwin Inc. M80-5501005	29.5 µin	0.75 µm	Shrouded - 4 Wall	Male Pin	2	Circular	Gold	2.2 A	5.6 mm	0.22 in	Gold	-55 C	125 °C	10	2 mm	0.079 in	29.5 µin	0.75 µm	Phosphor Bronze	800 VAC	0.079 "	2 mm	Keying Slot Mating Flange	0.118 in	3 mm	Solder	Black	Header	Right Angle Through Hole	Board to Board Cable	Push-Pull	All	UL94 V-0	Polyphenylene Sulfide (PPS) Glass Filled
Harwin Inc. M80-5501642	0.3 µm		Shrouded - 4 Wall	Male Pin	2	Circular	Gold	2.2 A	5.6 mm	0.22 in	Tin	-55 C	125 °C	16	2 mm	0.079 in	29.5 µin	0.75 µm	Phosphor Bronze	800 VAC	0.079 "	2 mm	Keying Slot Mating Flange	0.118 in	3 mm	Solder	Black	Header	Right Angle Through Hole	Board to Board Cable	Push-Pull	All	UL94 V-0	Polyphenylene Sulfide (PPS) Glass Filled	12 µin
Harwin Inc. M80-5500805	29.5 µin	0.75 µm	Shrouded - 4 Wall	Male Pin	2	Circular	Gold	2.2 A	5.6 mm	0.22 in	Gold	-55 C	125 °C	8	2 mm	0.079 in	29.5 µin	0.75 µm	Phosphor Bronze	800 VAC	0.079 "	2 mm	Keying Slot Mating Flange	0.118 in	3 mm	Solder	Black	Header	Right Angle Through Hole	Board to Board Cable	Push-Pull	All	UL94 V-0	Polyphenylene Sulfide (PPS) Glass Filled
Harwin Inc. M80-5503422			Shrouded - 4 Wall	Male Pin	2	Circular	Gold	2.2 A	5.55 mm	0.218 in	Tin-Lead	-55 C	125 °C		2 mm	0.079 in	29.5 µin	0.75 µm	Phosphor Bronze	120 VDC	0.079 "	2 mm	Keying Slot Mating Flange	0.118 in	3 mm	Solder	Black	Header	Right Angle Through Hole	Board to Board Cable	Push-Pull	All	UL94 V-0	Polyphenylene Sulfide (PPS) Glass Filled		118.1 µin	3 µm	34
Harwin Inc. M80-5500405	29.5 µin	0.75 µm	Shrouded - 4 Wall	Male Pin	2	Circular	Gold	2.2 A	5.6 mm	0.22 in	Gold	-55 C	125 °C	4	2 mm	0.079 in	29.5 µin	0.75 µm	Phosphor Bronze	800 VAC	0.079 "	2 mm	Keying Slot Mating Flange	0.118 in	3 mm	Solder	Black	Header	Right Angle Through Hole	Board to Board Cable	Push-Pull	All	UL94 V-0	Polyphenylene Sulfide (PPS) Glass Filled
Harwin Inc. M80-5505022			Shrouded - 4 Wall	Male Pin	2	Circular	Gold	2.2 A	5.55 mm	0.218 in	Tin-Lead	-55 C	125 °C	50	2 mm	0.079 in	29.5 µin	0.75 µm	Phosphor Bronze	120 VDC	0.079 "	2 mm	Keying Slot Mating Flange	0.118 in	3 mm	Solder	Black	Header	Right Angle Through Hole	Board to Board Cable	Push-Pull	All	UL94 V-0	Polyphenylene Sulfide (PPS) Glass Filled		118.1 µin	3 µm
Harwin Inc. M80-5502222	0.3 µm		Shrouded - 4 Wall	Male Pin	2	Circular	Gold	2.2 A			Tin-Lead	-55 C	125 °C	22	2 mm	0.079 in	29.5 µin	0.75 µm	Phosphor Bronze	800 VAC	0.079 "	2 mm	Keying Slot Mating Flange	0.118 in	3 mm	Solder	Black	Header	Right Angle Through Hole	Board to Board Cable	Push-Pull	All	UL94 V-0	Polyphenylene Sulfide (PPS) Glass Filled	12 µin				0.238 "	6.05 mm
Harwin Inc. M80-5500442	0.3 µm		Shrouded - 4 Wall	Male Pin	2	Circular	Gold	2.2 A	5.6 mm	0.22 in	Tin	-55 C	125 °C	4	2 mm	0.079 in	29.5 µin	0.75 µm	Phosphor Bronze	800 VAC	0.079 "	2 mm	Keying Slot Mating Flange	0.118 in	3 mm	Solder	Black	Header	Right Angle Through Hole	Board to Board Cable	Push-Pull	All	UL94 V-0	Polyphenylene Sulfide (PPS) Glass Filled	12 µin
