3070 Series

Catalog

WIRE, HOOK UP, UL1015, PVC, BROWN, 24 AWG, 0.23 MM², 1000 FT

Part	Ratings	Jacket Color	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Jacket (Insulation) Material	Operating Temperature [Min]	Operating Temperature [Max]	Length	Length	Wire Gauge	Conductor Strand [custom]	Conductor Strand [custom]	Cable Type	Voltage	Features	Length [x]	Length [x]
ALPHA WIRE 3070 BR001	ISO 10993 UL Style 1015	Brown	0.81 mm	0.032 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	-20 C	105 ░C	1000 ft	304.8 m	24 AWG	32 AWG	7	Hook-Up	600 V	Biological Compatibility
ALPHA WIRE 3070 RD005	ISO 10993 UL Style 1015	Red	0.81 mm	0.032 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	-20 C	105 ░C			24 AWG	32 AWG	7	Hook-Up	600 V	Biological Compatibility	30.5 m	100 ft
ALPHA WIRE 3070 BL005	ISO 10993 UL Style 1015	Blue	0.81 mm	0.032 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	-20 C	105 ░C			24 AWG	32 AWG	7	Hook-Up	600 V	Biological Compatibility	30.5 m	100 ft
ALPHA WIRE 3070 GR001	ISO 10993 UL Style 1015	Green	0.81 mm	0.032 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	-20 C	105 ░C	1000 ft	304.8 m	24 AWG	32 AWG	7	Hook-Up	600 V	Biological Compatibility
ALPHA WIRE 3070 OR001	ISO 10993 UL Style 1015	Orange	0.81 mm	0.032 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	-20 C	105 ░C	1000 ft	304.8 m	24 AWG	32 AWG	7	Hook-Up	600 V	Biological Compatibility
ALPHA WIRE 3070 GR005	ISO 10993 UL Style 1015	Green	0.81 mm	0.032 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	-20 C	105 ░C			24 AWG	32 AWG	7	Hook-Up	600 V	Biological Compatibility	30.5 m	100 ft
ALPHA WIRE 3070 BK001	ISO 10993 UL Style 1015	Black	0.81 mm	0.032 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	-20 C	105 ░C	1000 ft	304.8 m	24 AWG	32 AWG	7	Hook-Up	600 V	Biological Compatibility
ALPHA WIRE 3070 VI001	ISO 10993 UL Style 1015	Violet	0.81 mm	0.032 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	-20 C	105 ░C	1000 ft	304.8 m	24 AWG	32 AWG	7	Hook-Up	600 V	Biological Compatibility
ALPHA WIRE 3070 OR005	ISO 10993 UL Style 1015	Orange	0.81 mm	0.032 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	-20 C	105 ░C			24 AWG	32 AWG	7	Hook-Up	600 V	Biological Compatibility	30.5 m	100 ft
ALPHA WIRE 3070 WH001	ISO 10993 UL Style 1015		0.81 mm	0.032 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	-20 C	105 ░C	1000 ft	304.8 m	24 AWG	32 AWG	7	Hook-Up	600 V	Biological Compatibility
