395-051 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 51POS 0.100
| Part | Material - Insulation | Termination Rows | Read Out | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Contact Type | Number of Positions | Mounting Type | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row [custom] | Contact Finish | Flange Feature | Color | Pitch | Pitch | Features | Card Type | Termination | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 1 | -40 C | 105 ░C | Female | Cantilever | 51 | Through Hole | Copper Alloy | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 51 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Black | 0.1 " | 2.54 mm | Card Guides | Non Specified - Single Edge | Wire Wrap | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 1 | -40 C | 105 ░C | Female | Cantilever | 51 | Right Angle Through Hole | Copper Alloy | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 51 | Gold | Floating Bobbin Top Mount Opening | Black | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | 0.116 " | 2.95 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 1 | -40 C | 105 ░C | Female | Cantilever | 51 | Through Hole | Copper Alloy | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 51 | Gold | 4-40 Threaded Insert Top Mount Opening | Black | 0.1 " | 2.54 mm | Card Guides | Non Specified - Single Edge | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 1 | -40 C | 105 ░C | Female | Cantilever | 51 | Through Hole | Copper Alloy | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 51 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Black | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 1 | -40 C | 105 ░C | Female | Cantilever | 51 | Through Hole | Copper Alloy | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 51 | Gold | 4-40 Threaded Insert Top Mount Opening | Black | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 1 | -40 C | 105 ░C | Female | Cantilever | 51 | Through Hole | Copper Alloy | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 51 | Gold | M3 Threaded Insert Top Mount Opening | Black | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 1 | -40 C | 105 ░C | Female | Cantilever | 51 | Through Hole | Copper Alloy | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 51 | Gold | Flush Mount M3 Threaded Insert Top Opening | Black | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 1 | -40 C | 105 ░C | Female | Cantilever | 51 | Through Hole | Copper Alloy | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 51 | Gold | 4-40 Threaded Insert Top Mount Opening | Black | 0.1 " | 2.54 mm | Card Guides | Non Specified - Single Edge | Wire Wrap | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 1 | -40 C | 105 ░C | Female | Cantilever | 51 | Through Hole | Copper Alloy | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 51 | Gold | Flush Mount Side Opening Unthreaded | Black | 0.1 " | 2.54 mm | Non Specified - Single Edge | Solder | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 1 | -40 C | 105 ░C | Female | Cantilever | 51 | Through Hole | Copper Alloy | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 51 | Gold | 4-40 Threaded Insert Top Mount Opening | Black | 0.1 " | 2.54 mm | Card Guides | Non Specified - Single Edge | Solder |
