11_C-50 Series
Manufacturer: Huber+Suhner, Inc.
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
11_C-50-3-7/133_NE
| Part | Mounting Type | Fastening Type | Impedance | Housing Color | Shield Termination | Connector Type | Center Contact Material | Frequency - Max | Contact Termination | Connector Style | Cable Group | Number of Ports | Operating Temperature (Min) | Operating Temperature (Max) | Body Finish | Body Material | Center Contact Plating | Dielectric Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | Free Hanging (In-Line) | Bayonet Lock | 50 Ohm | Silver | Crimp | Male Pin Plug | Brass | 11 GHz | Crimp | C Type | RG-58 | 1 | -65 °C | 165 °C | White Bronze | Brass | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) |
 Huber+Suhner, Inc. | Free Hanging (In-Line) | Bayonet Lock | 50 Ohm | Silver | Clamp | Male Pin Plug | Brass | 11 GHz | Solder | C Type | RG-214 | 1 | -65 °C | 165 °C | White Bronze | Brass | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) |
 Huber+Suhner, Inc. | Free Hanging (In-Line) | Bayonet Lock | 50 Ohm | Silver | Clamp | Male Pin Plug | Brass | 11 GHz | Crimp | C Type | RG-214 | 1 | -65 °C | 165 °C | White Bronze | Brass | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) |
