316-011 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 22POS 0.156
| Part | Material - Insulation | Termination Rows | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Mounting Type | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Features | Read Out | Pitch | Pitch | Number of Positions/Bay/Row | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Color | Contact Type | Contact Material | Gender | Number of Rows [custom] | Termination | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | -40 C | 105 ░C | Gold | Through Hole | 22 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | Dual | 3.96 mm | 0.156 in | 11 | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Green | Cantilever | Copper Alloy | Female | 2 | Solder | ||
EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | Panel Mount | 22 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | Dual | 3.96 mm | 0.156 in | 11 | 4-40 Flush Mount Threaded Insert Top Opening | Green | Cantilever | Copper Alloy | Female | 2 | Solder Eyelet(s) | ||||
EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | Panel Mount Through Hole | 22 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 3.96 mm | 0.156 in | 11 | 4-40 Flush Mount Threaded Insert Top Opening | Green | Cantilever | Copper Alloy | Female | 2 | Solder | |||||
EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | -40 C | 105 ░C | Gold | Through Hole | 22 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 3.96 mm | 0.156 in | 11 | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | Green | Cantilever | Copper Alloy | Female | 2 | Solder | 3.25 mm | 0.128 " | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | Panel Mount | 22 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 3.96 mm | 0.156 in | 11 | Flush Mount Top Opening Unthreaded | Green | Cantilever | Copper Alloy | Female | 2 | Solder Eyelet(s) | 3.25 mm | 0.128 " | |||
EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | Panel Mount Through Hole | 22 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | Dual | 3.96 mm | 0.156 in | 11 | 4-40 Flush Mount Threaded Insert Top Opening | Green | Cantilever | Copper Alloy | Female | 2 | Solder | ||||
EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | Panel Mount Through Hole | 22 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 3.96 mm | 0.156 in | 11 | Flush Mount Side Opening Unthreaded | Green | Cantilever | Copper Alloy | Female | 2 | Solder | 3.25 mm | 0.128 " | |||
EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | -40 C | 105 ░C | Gold | Through Hole | 22 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 3.96 mm | 0.156 in | 11 | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Green | Cantilever | Copper Alloy | Female | 2 | Solder | |||
EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | Free Hanging (In-Line) | 22 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 3.96 mm | 0.156 in | 11 | Green | Cantilever | Copper Alloy | Female | 2 | Solder Eyelet(s) | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | Panel Mount Through Hole | 22 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 3.96 mm | 0.156 in | 11 | Floating Bobbin Flush Mount | Green | Cantilever | Copper Alloy | Female | 2 | Solder | 2.95 mm | 0.116 " |
