109-044 Series
Manufacturer: Sanyo Denki America Inc.
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
FAN 80X42MM 230VAC
| Part | Bearing Type | Static Pressure | Operating Temperature (Min) | Operating Temperature (Max) | Power (Watts) | Weight | Voltage - Rated | Noise | Size / Dimension Length | Size / Dimension Shape | Size / Dimension Height | Fan Type | Termination Count | Termination | RPM | Width | Approval Agency | Air Flow | Material - Blade | Current Rating | Lifetime | Material - Frame |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sanyo Denki America Inc. | Ball | 0.142 in H2O | -22 °F | 140 °F | 9 W | 0.904 lb | 230 VAC | 44 dB | 80 mm | Square | 80 mm | Tubeaxial | 2 | 2 Terminals | 3100 RPM | 42 mm | CE CSA PSE TUV UL | 35.3 CFM | Plastic | 50 mA | 25000 Hrs | Aluminum |
