B3J Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
SWITCH: KEYPAD; POS: 2; SPST-NO; 0.05A/24VDC; ORANGE; NONE; THT; BOX
| Part | Electrical Life | Mechanical Life | Termination Style | Type | Color - Actuator/Cap | Switch Function | Actuator Marking | Circuit | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Voltage Rating - DC | Actuator Type | Current Rating (Amps) | Illumination Type, Color | Illumination Voltage (Nominal) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | 3000000 Cycles | 3000000 Cycles | PC Pin | Keyswitch | Orange | Off-Mom | No Marking | SPST-NO | -25 °C | 70 °C | Through Hole | 24 V | Button Square | 50 mA | ||
 Omron Electronics Inc-EMC Div | 3000000 Cycles | 3000000 Cycles | PC Pin | Keyswitch Illuminated | Gray Light | Off-Mom | No Marking | SPST-NO | -25 °C | 70 °C | Through Hole | 24 V | Button Square | 50 mA | Green/Red LED | 2 VDC 2.1 VDC |
 Omron Electronics Inc-EMC Div | 3000000 Cycles | 3000000 Cycles | PC Pin | Keyswitch Illuminated | Gray Light | Off-Mom | No Marking | SPST-NO | -25 °C | 70 °C | Through Hole | 24 V | Button Square | 50 mA | LED Red | 2 VDC |
 Omron Electronics Inc-EMC Div | 3000000 Cycles | 3000000 Cycles | PC Pin | Keyswitch Illuminated | Gray Light | Off-Mom | No Marking | SPST-NO | -25 °C | 70 °C | Through Hole | 24 V | Button Square | 50 mA | Green LED | 2.1 VDC |
 Omron Electronics Inc-EMC Div | 3000000 Cycles | 3000000 Cycles | PC Pin | Keyswitch Illuminated | Yellow | Off-Mom | No Marking | SPST-NO | -25 °C | 70 °C | Through Hole | 24 V | Button Square | 50 mA | Green/Red LED | 2 VDC 2.1 VDC |
 Omron Electronics Inc-EMC Div | 3000000 Cycles | 3000000 Cycles | PC Pin | Keyswitch Illuminated | Yellow | Off-Mom | No Marking | SPST-NO | -25 °C | 70 °C | Through Hole | 24 V | Button Square | 50 mA | LED Red | 2 VDC |
 Omron Electronics Inc-EMC Div | 3000000 Cycles | 3000000 Cycles | PC Pin | Keyswitch Illuminated | Black | Off-Mom | No Marking | SPST-NO | -25 °C | 70 °C | Through Hole | 24 V | Button Square | 50 mA | LED Yellow | 2 VDC |
Omron Electronics Inc-EMC Div | 3000000 Cycles | 3000000 Cycles | PC Pin | Keyswitch Illuminated | Orange | Off-Mom | No Marking | SPST-NO | -25 °C | 70 °C | Through Hole | 24 V | Button Square | 50 mA | Green/Red LED | 2 VDC 2.1 VDC |
Omron Electronics Inc-EMC Div | 3000000 Cycles | 3000000 Cycles | PC Pin | Keyswitch Illuminated | Blue | Off-Mom | No Marking | SPST-NO | -25 °C | 70 °C | Through Hole | 24 V | Button Square | 50 mA | LED Yellow | 2 VDC |
 Omron Electronics Inc-EMC Div | 3000000 Cycles | 3000000 Cycles | PC Pin | Keyswitch Illuminated | Gray Light | Off-Mom | No Marking | SPST-NO | -25 °C | 70 °C | Through Hole | 24 V | Button Square | 50 mA | LED Red Yellow | 2 VDC |
