PCC08 Series

Catalog

CONN HEADER VERT 16POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish - Post	Contact Material	Pitch - Mating	Pitch - Mating	Insulation Material	Fastening Type	Contact Length - Mating	Contact Length - Mating	Shrouding	Overall Contact Length [x]	Overall Contact Length [x]	Current Rating (Amps)	Insulation Height	Insulation Height	Contact Type	Contact Length - Post	Contact Length - Post	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Positions Loaded	Contact Shape	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Style	Number of Rows [custom]	Number of Positions	Material Flammability Rating	Termination	Contact Finish - Mating	Mounting Type	Insulation Color
Sullins Connector Solutions PCC08DAAN	2.54 µm	100 µin	Tin	Phosphor Bronze	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	Push-Pull	0.23 in	5.84 mm	Unshrouded	11.43 mm	0.45 in	3 A	0.1 in	2.54 mm	Male Pin	3.05 mm	0.12 in	0.1 in	2.54 mm	All	Square	0.76 Ám	30 Áin	-65 ░C	125 °C	Header Breakaway	Board to Board Cable	2	16	UL94 V-0	Solder	Gold	Through Hole	Black
