837-042 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 42POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Gender | Card Type | Number of Positions/Bay/Row [custom] | Number of Positions | Color | Termination | Flange Feature | Mounting Type | Pitch | Pitch | Contact Finish | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Features | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Number of Rows [custom] | Read Out | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Rows | Number of Positions/Bay/Row |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 21 | 42 | Green | Solder | Flush Mount M3 Threaded Insert Top Opening | Board Edge Straddle Mount | 3.96 mm | 0.156 in | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Card Extender | 0.25 Ám | 10 Áin | Cantilever | 2 | Dual | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 21 | 42 | Green | Solder | Board Edge Straddle Mount | 3.96 mm | 0.156 in | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Card Extender | 0.25 Ám | 10 Áin | Cantilever | 2 | Dual | 3.25 mm | 0.128 " | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 21 | 42 | Green | Wire Wrap | Through Hole | 3.96 mm | 0.156 in | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | Dual | 3.25 mm | 0.128 " | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 21 | 42 | Green | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 3.96 mm | 0.156 in | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | Dual | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 21 | 42 | Green | Solder | Through Hole | 3.96 mm | 0.156 in | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | Dual | 3.96 mm | 0.156 " | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Non Specified - Single Edge | 42 | Green | Solder | Flush Mount Top Opening Unthreaded | Through Hole | 3.96 mm | 0.156 in | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Single | 3.25 mm | 0.128 " | 1 | 1 | 42 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Non Specified - Single Edge | 42 | Green | Solder | Floating Bobbin Top Mount Opening | Right Angle Through Hole | 3.96 mm | 0.156 in | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Single | 2.95 mm | 0.116 " | 1 | 1 | 42 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Non Specified - Single Edge | 42 | Green | Wire Wrap | 4-40 Threaded Insert Top Mount Opening | Through Hole | 3.96 mm | 0.156 in | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Single | 1 | 1 | 42 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Non Specified - Single Edge | 42 | Green | Solder Eyelet(s) | Flush Mount Top Opening Unthreaded | Through Hole | 3.96 mm | 0.156 in | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Single | 3.25 mm | 0.128 " | 1 | 1 | 42 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Non Specified - Single Edge | 42 | Green | Solder | Flush Mount Top Opening Unthreaded | Through Hole | 3.96 mm | 0.156 in | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Single | 3.96 mm | 0.156 " | 1 | 1 | 42 |
