VSML2512S2 Series

Catalog

RES SMD 800 UOHM 1% 2W 2512

Part	Tolerance	Number of Terminations [custom]	Composition	Features	Temperature Coefficient	Operating Temperature [Min]	Operating Temperature [Max]	Ratings	Supplier Device Package	Power (Watts)	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Package / Case	Resistance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Package / Case
Delta Electronics/Cyntec VSML2512S2-0M80F	1 %	2	Thick Film	Automotive AEC-Q200 Current Sense Pulse Withstanding	100 ppm/°C	-65 ░C	170 °C	AEC-Q200	2512	2 W	0.126 in	3.2 mm	0.25 in	6.35 mm	2512 (6432 Metric)	0.8 mOhms	0.033 in	0.85 mm
Delta Electronics/Cyntec VSML2512S2-R008F	1 %	2	Thick Film	Automotive AEC-Q200 Current Sense Pulse Withstanding	50 ppm/░C	-65 ░C	170 °C	AEC-Q200	2512	2 W	0.126 in	3.2 mm	0.25 in	6.35 mm	2512 (6432 Metric)	8 mOhms	0.033 in	0.85 mm
Delta Electronics/Cyntec VSML2512S2-0M50F	1 %	2	Thick Film	Automotive AEC-Q200 Current Sense Pulse Withstanding	100 ppm/°C	-65 ░C	170 °C	AEC-Q200	2512	2 W	0.126 in	3.2 mm	0.25 in	6.35 mm	2512 2512 (6432 Metric)	0.5 mOhms	0.033 in	0.85 mm	6332 Metric
Delta Electronics/Cyntec VSML2512S2-R001F	1 %	2	Thick Film	Automotive AEC-Q200 Current Sense Pulse Withstanding	75 ppm/°C	-65 ░C	170 °C	AEC-Q200	2512	2 W	0.126 in	3.2 mm	0.25 in	6.35 mm	2512 2512 (6432 Metric)	1 mOhms	0.033 in	0.85 mm	6332 Metric
