ec3a-e Series

Manufacturer: Cincon Electronics Co. LTD

Catalog

Catalog

CONVERTER: DC/DC; 3W; UIN: 36÷72VDC; UOUT: 15VDC; 15V; UOUT2: -15VDC

...

Part	Voltage - Output 2	Mounting Type	Standard Number	Voltage - Isolation	Voltage - Input (Max) [Max]	Voltage - Output 1	Operating Temperature [Min]	Operating Temperature [Max]	Features	Efficiency	Type	Power (Watts)	Approval Agency	Voltage - Input (Min) [Min]	Applications	Current - Output (Max)	Current - Output (Max)	Package / Case	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Number of Outputs	Current - Output (Max) [Max]	Control Features	Size / Dimension [y]	Size / Dimension [z]	Current - Output (Max)
Cincon Electronics Co. LTD EC3A36H-E	-15 V	Through Hole	60950-1	3000 V	72 V	15 V	-40 °C	100 °C	OCP SCP UVLO	87 %	Isolated Module	3 W	CE cURus	36 V	ITE (Commercial)	100 mA	100 mA	24-DIP Module 14 Leads	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	2
Cincon Electronics Co. LTD EC3A17-E		Through Hole	60950-1	500 V	18 V	3.3 V	-40 °C	100 °C	OCP SCP UVLO	78 %	Isolated Module	2 W	CE cURus	9 V	ITE (Commercial)			24-DIP Module 14 Leads	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	1	600 mA
Cincon Electronics Co. LTD EC3A13MS-E		Surface Mount	60950-1 62368-1	500 V	18 V	15 V	-40 C	85 °C	Adjustable Output Remote On/Off	85 %	Isolated Module	3 W	CE cURus	9 V	ITE (Commercial)			24-SMD Module 18 Leads	0.8 "	0.45 in	31.8 mm			1.25 in	1	200 mA	Active High Enable	20.3 mm	11.4 mm
Cincon Electronics Co. LTD EC3A25HMS-E	-12 V	Surface Mount	60950-1 62368-1	1.5 kV	36 V	12 V	-40 C	85 °C	Adjustable Output Remote On/Off	85 %	Isolated Module	3 W	CE cURus	18 V	ITE (Commercial)			24-SMD Module 18 Leads	0.8 "	0.45 in	31.8 mm			1.25 in	2		Active High Enable	20.3 mm	11.4 mm	125 mA
Cincon Electronics Co. LTD EC3A22MS-E		Surface Mount	60950-1 62368-1	500 V	36 V	12 V	-40 C	85 °C	Adjustable Output Remote On/Off	86 %	Isolated Module	3 W	CE cURus	18 V	ITE (Commercial)			24-SMD Module 18 Leads	0.8 "	0.45 in	31.8 mm			1.25 in	1	250 mA	Active High Enable	20.3 mm	11.4 mm
Cincon Electronics Co. LTD EC3A34MS-E	-5 V	Surface Mount	60950-1 62368-1	500 V	72 V	5 V	-40 C	85 °C	Adjustable Output Remote On/Off	85 %	Isolated Module	3 W	CE cURus	36 V	ITE (Commercial)			24-SMD Module 18 Leads	0.8 "	0.45 in	31.8 mm			1.25 in	2	0.3 A	Active High Enable	20.3 mm	11.4 mm
Cincon Electronics Co. LTD EC3A26HS-E	-15 V	Surface Mount	60950-1 62368-1	3000 V	36 V	15 V	-40 C	85 °C	Adjustable Output Remote On/Off	86 %	Isolated Module	3 W	CE cURus	18 V	ITE (Commercial)	100 mA	100 mA	24-SMD Module 18 Leads	0.8 "	0.45 in	31.8 mm			1.25 in	2		Active High Enable	20.3 mm	11.4 mm
Cincon Electronics Co. LTD EC3A25MS-E	-12 V	Surface Mount	60950-1 62368-1	500 V	36 V	12 V	-40 C	85 °C	Adjustable Output Remote On/Off	85 %	Isolated Module	3 W	CE cURus	18 V	ITE (Commercial)			24-SMD Module 18 Leads	0.8 "	0.45 in	31.8 mm			1.25 in	2		Active High Enable	20.3 mm	11.4 mm	125 mA
Cincon Electronics Co. LTD EC3A31-E		Through Hole	60950-1	500 V	72 V	5 V	-40 °C	100 °C	OCP SCP UVLO	84 %	Isolated Module	3 W	CE cURus	36 V	ITE (Commercial)			24-DIP Module 14 Leads	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	1	600 mA
Cincon Electronics Co. LTD EC3A02HMS-E		Surface Mount	60950-1 62368-1	1.5 kV	9 V	12 V	-40 C	85 °C	Adjustable Output Remote On/Off	80 %	Isolated Module	3 W	CE cURus	4.5 V	ITE (Commercial)			24-SMD Module 18 Leads	0.8 "	0.45 in	31.8 mm			1.25 in	1	250 mA	Active High Enable	20.3 mm	11.4 mm
