857-035 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 35POS 0.156
| Part | Termination Rows | Material - Insulation | Gender | Contact Finish | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Mounting Type | Color | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Card Type | Contact Type | Pitch | Pitch | Termination | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Flange Feature | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Gold | Copper Alloy | 0.25 Ám | 10 Áin | 1 | Through Hole | Black | 125 °C | -40 C | Single | Non Specified - Single Edge | Semi Bellows | 3.96 mm | 0.156 in | Solder | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Tin | Copper Alloy | 1 | Right Angle Through Hole | Black | 125 °C | -40 C | Single | Non Specified - Single Edge | Semi Bellows | 3.96 mm | 0.156 in | Solder | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Tin | Copper Alloy | 1 | Right Angle Through Hole | Black | 125 °C | -40 C | Single | Non Specified - Single Edge | Semi Bellows | 3.96 mm | 0.156 in | Solder | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Gold | Copper Alloy | 0.25 Ám | 10 Áin | Right Angle Through Hole | Black | 125 °C | -40 C | Dual | Non Specified - Dual Edge | Semi Bellows | 3.96 mm | 0.156 in | Solder | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | 4-40 Flush Mount Threaded Insert Top Opening | 2 | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Gold | Copper Alloy | 0.25 Ám | 10 Áin | 1 | Through Hole | Black | 125 °C | -40 C | Single | Non Specified - Single Edge | Semi Bellows | 3.96 mm | 0.156 in | Solder Eyelet(s) | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Tin | Copper Alloy | 1 | Through Hole | Black | 125 °C | -40 C | Single | Non Specified - Single Edge | Semi Bellows | 3.96 mm | 0.156 in | Wire Wrap | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Gold | Copper Alloy | 0.25 Ám | 10 Áin | 1 | Through Hole | Black | 125 °C | -40 C | Single | Non Specified - Single Edge | Semi Bellows | 3.96 mm | 0.156 in | Wire Wrap | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Tin | Copper Alloy | 1 | Through Hole | Black | 125 °C | -40 C | Single | Non Specified - Single Edge | Semi Bellows | 3.96 mm | 0.156 in | Wire Wrap | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Tin | Copper Alloy | 1 | Through Hole | Black | 125 °C | -40 C | Single | Non Specified - Single Edge | Semi Bellows | 3.96 mm | 0.156 in | Solder | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Gold | Copper Alloy | 0.25 Ám | 10 Áin | 1 | Through Hole | Black | 125 °C | -40 C | Single | Non Specified - Single Edge | Semi Bellows | 3.96 mm | 0.156 in | Solder | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 |
