MHV12 Series
Manufacturer: Bellnix Co., Ltd.
Beta
⌘K
DC DC CONVERTER -470V 2.6W
| Part | Number of Outputs | Package / Case | Voltage - Input (Min) [Min] | Features | Mounting Type | Current - Output (Max) [Max] | Voltage - Input (Max) [Max] | Voltage - Output 1 | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Applications | Power (Watts) | Type | Operating Temperature [Min] | Operating Temperature [Max] | Control Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bellnix Co., Ltd. | 1 | 7-SIP Module | 10.8 V | Adjustable Output Remote On/Off | Through Hole | 5.6 mA | 13.2 V | -470 V | 12 mm | 110 mm | 4.33 in | 0.47 " | 0.78 in | 19.8 mm | ITE (Commercial) | 2.6 W | High Voltage - Non-Isolated Module | -10 °C | 60 °C | Active Low Enable |
Bellnix Co., Ltd. | 1 | 7-SIP Module | 10.8 V | Adjustable Output Remote On/Off | Through Hole | 2 mA | 16.5 V | -1000 V | 12 mm | 110 mm | 4.33 in | 0.47 " | 0.78 in | 19.8 mm | ITE (Commercial) | 2 W | High Voltage - Non-Isolated Module | -10 °C | 60 °C | Active Low Enable |
Bellnix Co., Ltd. | 1 | 7-SIP Module | 10.8 V | Adjustable Output Remote On/Off | Through Hole | 2 mA | 16.5 V | 1000 V | 12 mm | 110 mm | 4.33 in | 0.47 " | 0.78 in | 19.8 mm | ITE (Commercial) | 2 W | High Voltage - Non-Isolated Module | -10 °C | 60 °C | Active High Enable |
Bellnix Co., Ltd. | 1 | 7-SIP Module | 10.8 V | Adjustable Output Remote On/Off | Through Hole | 5.6 mA | 13.2 V | 470 V | 12 mm | 110 mm | 4.33 in | 0.47 " | 0.78 in | 19.8 mm | ITE (Commercial) | 2.6 W | High Voltage - Non-Isolated Module | -10 °C | 60 °C | Active High Enable |
