887-021 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 21POS 0.156
| Part | Termination Rows | Material - Insulation | Contact Material | Card Type | Number of Rows | Gender | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Color | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Read Out | Pitch | Pitch | Termination | Number of Positions/Bay/Row [custom] | Number of Positions | Mounting Type | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Non Specified - Single Edge | 1 | Female | Gold | 125 °C | -40 C | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Single | 3.96 mm | 0.156 in | Wire Wrap | 21 | 21 | Through Hole | 0.25 Ám | 10 Áin |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Non Specified - Single Edge | 1 | Female | Gold | 125 °C | -40 C | 0.156 " | 3.96 mm | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Single | 3.96 mm | 0.156 in | Wire Wrap | 21 | 21 | Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Non Specified - Single Edge | 1 | Female | Gold | 125 °C | -40 C | 0.156 " | 3.96 mm | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Single | 3.96 mm | 0.156 in | Wire Wrap | 21 | 21 | Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Non Specified - Single Edge | 1 | Female | Gold | 125 °C | -40 C | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Single | 3.96 mm | 0.156 in | Wire Wrap | 21 | 21 | Through Hole | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Non Specified - Single Edge | 1 | Female | Gold | 125 °C | -40 C | 0.128 " | 3.25 mm | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Single | 3.96 mm | 0.156 in | Solder | 21 | 21 | Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Non Specified - Single Edge | 1 | Female | Gold | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Single | 3.96 mm | 0.156 in | Wire Wrap | 21 | 21 | Through Hole | 0.25 Ám | 10 Áin |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Non Specified - Single Edge | 1 | Female | Gold | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Single | 3.96 mm | 0.156 in | Solder | 21 | 21 | Through Hole | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Non Specified - Single Edge | 1 | Female | Gold | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Single | 3.96 mm | 0.156 in | Wire Wrap | 21 | 21 | Through Hole | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Non Specified - Single Edge | 1 | Female | Gold | 125 °C | -40 C | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Single | 3.96 mm | 0.156 in | Solder | 21 | 21 | Through Hole | 0.25 Ám | 10 Áin |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Non Specified - Single Edge | 1 | Female | Gold | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Single | 3.96 mm | 0.156 in | Solder | 21 | 21 | Through Hole | 0.25 Ám | 10 Áin |
