209208 Series
Manufacturer: Molex
Beta
⌘K
KK PLUS 300 HEADER, 3.00MM PITCH, VERTICAL, FULLY SHROUDED, TIN (SN) PLATING, 2 CIRCUITS, WITH PEG, GLOW-WIRE CAPABLE
| Part | Current Rating (Amps) | Number of Positions Loaded | Fastening Type | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Material | Voltage Rating | Connector Type | Shrouding | Insulation Height | Insulation Height | Number of Rows | Features | Insulation Color | Material Flammability Rating | Contact Length - Post | Contact Length - Post | Termination | Contact Material | Contact Shape | Contact Finish - Post | Number of Positions | Pitch - Mating | Pitch - Mating | Contact Type | Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Varies by Wire Gauge | All | Latch Holder | Through Hole | -40 °C | 105 ░C | Liquid Crystal Polymer (LCP) | 250 VAC | Header | Shrouded - 4 Wall | 0.278 in | 7.06 mm | 1 | Board Guide | Black | UL94 V-0 | 3.15 mm | 0.124 " | Solder | Copper Alloy | Square | Tin | 2 | 0.118 in | 3 mm | Male Pin | Board to Cable/Wire |
 Molex | Varies by Wire Gauge | All | Latch Holder | Through Hole | -40 °C | 105 ░C | Liquid Crystal Polymer (LCP) | 250 VAC | Header | Shrouded - 4 Wall | 0.278 in | 7.06 mm | 1 | Board Guide | Black | UL94 V-0 | 3.15 mm | 0.124 " | Solder | Copper Alloy | Square | Tin | 4 | 0.118 in | 3 mm | Male Pin | Board to Cable/Wire |
 Molex | Varies by Wire Gauge | All | Latch Holder | Through Hole | -40 °C | 105 ░C | Liquid Crystal Polymer (LCP) | 250 VAC | Header | Shrouded - 4 Wall | 0.278 in | 7.06 mm | 1 | Board Guide | Black | UL94 V-0 | 3.15 mm | 0.124 " | Solder | Copper Alloy | Square | Tin | 0.118 in | 3 mm | Male Pin | Board to Cable/Wire |
